Processor
|
Intel Core i7-11800H (8C / 16T, 2.3 / 4.6GHz, 24MB)
|
Graphics
|
NVIDIA GeForce RTX 3060 6GB GDDR6, Boost Clock 1425 / 1702MHz, TGP 130W
|
Chipset
|
Intel HM570 Chipset
|
Memory
|
2x 8GB SO-DIMM DDR4-3200
|
Memory Slots
|
Two DDR4 SO-DIMM slots, dual-channel capable
|
Max Memory
|
Up to 32GB DDR4-3200 offering
|
Storage
|
512GB SSD M.2 2280 PCIe 4.0x4 NVMe
|
Storage Support
|
Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 512GB • M.2 2280 SSD up to 1TB
|
Storage Slot
|
Two M.2 slots • One M.2 2280 PCIe 3.0 x4 slot • One M.2 2280 PCIe 4.0 x4 slot
|
Card Reader
|
None
|
Optical
|
None
|
Audio Chip
|
High Definition (HD) Audio, Realtek ALC3306 codec
|
Speakers
|
Stereo speakers, 2W x2, Nahimic Audio
|
Camera
|
HD 720p with E-shutter
|
Microphone
|
2x, Array
|
Battery
|
Integrated 80Wh
|
Power Adapter
|
230W Slim Tip (3-pin)
|
DESIGN
|
Display
|
15.6" FHD (1920x1080) IPS 300nits Anti-glare, 100% sRGB, 165Hz, Dolby Vision, G-SYNC
|
Touchscreen
|
None
|
Keyboard
|
4-Zone RGB Backlit, Arabic
|
Case Color
|
Phantom Blue (Top), Shadow Black (Bottom)
|
Surface Treatment
|
Painting
|
Case Material
|
PC-ABS (Top), PC-ABS (Bottom)
|
Dimensions (WxDxH)
|
362.56 x 260.61 x 22.5-25.75 mm (14.27 x 10.26 x 0.89-1.01 inches)
|
Weight
|
Around 2.4 kg (5.3 lbs)
|
SOFTWARE
|
Operating System
|
None
|
Bundled Software
|
None
|
CONNECTIVITY
|
Ethernet
|
100/1000M (RJ-45)
|
WLAN + Bluetooth
|
Wi-Fi 6, 11ax 2x2 + BT5.1
|
Standard Ports
|
- 1x Ethernet (RJ-45)
- 1x HDMI 2.1
- 1x Headphone / microphone combo jack (3.5mm)
- 1x Power connector
- 1x Thunderbolt 4 / USB4 40Gbps (support data transfer and DisplayPort 1.4)
- 1x Thunderbolt 4 / USB4 40Gbps (support data transfer, Power Delivery and DisplayPort 1.4)
- 1x USB 3.2 Gen 1 (Always On)
- 3x USB 3.2 Gen 1
|
Security Chip
|
Firmware TPM 2.0
|
Fingerprint Reader
|
None
|
Other Security
|
E-shutter
|
SERVICE
|
Base Warranty
|
1-year, Courier or Carry-in
|
Included Upgrade
|
2Y Courier/Carry-in upgrade from 1Y Courier/Carry-in
|
ACCESSORIES
|
Bundled Accessories
|
Lenovo Legion M300 RGB Gaming Mouse
|
CERTIFICATIONS
|
Green Certifications
|
|
