Part No
|
90NR0845-M00JP0
|
Model Name
|
G513RM-HF007W
|
|
|
EAN Code
|
4711081813149
|
UPC Code
|
195553813143
|
|
|
Marketing Name
|
ROG Strix G15
|
Color
|
Eclipse Gray
|
Dimension (W x D x H)
|
35.4 x 25.9 x 2.26 ~ 2.72 cm (13.94" x 10.20" x 0.89" ~ 1.07")
|
Weight
|
2.30 Kg (5.07 lbs)
|
Processor
|
AMD Ryzen 7 6800H Mobile Processor (8-core/16-thread, 20MB cache, up to 4.7 GHz max boost)
|
Chipset
|
N/A
|
Discrete/Optimus
|
MUX Switch + Optimus
|
Graphic
|
NVIDIA GeForce RTX 3060 Laptop GPU
|
Graphic Wattage
|
ROG Boost: 1752MHz* at 140W (1702MHz Boost Clock+50MHz OC, 115W+25W Dynamic Boost)
|
Graphic Memory
|
6GB GDDR6
|
IGPU
|
AMD Radeon Graphics
|
Panel Size
|
15.6-inch
|
Resolution
|
FHD (1920 x 1080) 16:9
|
Refresh Rate
|
300Hz
|
Response Time (G2G)
|
3ms
|
Viewing Angle
|
170
|
Panel Tech
|
IPS-level
|
Brightness
|
300nits
|
Contrast
|
1:1000
|
NTSC %
|
72%
|
SRGB %
|
100.00%
|
Adobe %
|
75.35%
|
Anti glare
|
Anti-glare display
|
Adaptive-Sync technology
|
Adaptive-Sync
|
Pantone
|
N/A
|
Support Dolby Vision HDR
|
Yes
|
On board memory
|
N/A
|
DIMM Memory
|
8GB DDR5-4800 SO-DIMM *2
|
Total System Memory
|
DDR5 16GB
|
Memory Slot
|
2x SO-DIMM slots
|
Memory Max.
|
32GB
|
Multi-channel memory technology
|
Support dual channel memory
|
System Storage Installed
|
1TB PCIe 4.0 NVMe M.2 SSD
|
M.2 slots support either SATA or NVMe
|
2
|
M.2 SSD Support List
|
M.2 512GB PCIe
M.2 1TB PCIe
|
Expansion Slot (includes used)
|
2x DDR5 SO-DIMM slots
2x PCIe
|
LAN
|
10/100/1000/2500 Mbps
|
Wi-Fi/Bluetooth
|
Wi-Fi 6E(802.11ax) (Triple band) 2*2 + Bluetooth 5.3 Wireless Card (*Bluetooth version may change with OS version different.) -RangeBoost
|
I/O Ports
|
1x RJ45 LAN port
1x USB 3.2 Gen 2 Type-C
1x USB 3.2 Gen 2 Type-C support DisplayPort™ / power delivery / G-SYNC
2x USB 3.2 Gen 1 Type-A
|
Display output
|
1x HDMI 2.1 TMDS
|
Audio
|
1x 3.5mm Combo Audio Jack
|
Webcam
|
N/A
|
Mic
|
Built-in array microphone
|
Keyboard Type
|
Backlit Chiclet Keyboard 4-Zone RGB
|
NumberPad
|
N/A
|
Aura Sync
|
Yes
|
Speakers
|
2-speaker system with Smart Amplifier Technology
|
Audio Tech
|
AI noise-canceling technology
Dolby Atmos
Hi-Res certification
Smart Amp Technology
|
Operating System
|
Windows 11 Home
|
Antivirus
|
MCAFEE_30D
|
Xbox Game Pass
|
Xbox Game Pass Ultimate_1 month (*Terms and exclusions apply. Offer only available in eligible markets for Xbox Game Pass Ultimate. Eligible markets are determined at activation. Game catalog varies by region, device, and time.)
|
Security
|
BIOS Administrator Password and User Password Protection
Trusted Platform Module (Firmware TPM)
|
Battery
|
90WHrs, 4S1P, 4-cell Li-ion
|
Fast charging
|
Recharge from 0-50% in 30 minutes
|
Power
|
ø6.0, 240W AC Adapter, Output: 20V DC, 12A, 240W, Input: 100~240C AC 50/60Hz universal
|
Reparability Index (for FR)
|
7.3
|
