CORE I5-14400F - MSI PRO B760M-E - RAM 8X2 3200 Bundle
CORE I5-14400F - MSI PRO B760M-E - RAM 8X2 3200 Bundle is backordered and will ship as soon as it is back in stock.
Pickup available at Bostan Mall , 10th Floor , Bab Al Louq, Abdeen, Egypt
Usually ready in 24 hours
Delivery and Shipping
Delivery and Shipping
Fast shipping to your doorstep! Get your order delivered within 1-5 days based on location.
Subscribe to our newsletter
Sign up for exclusive offers.
Description
Description
CORE I5-14400F - MSI PRO B760M-E - RAM PATRIOT 8X2 3200 Bundle
CORE I5-14400F
Code Name
Products formerly Raptor Lake
Vertical Segment
Desktop
Processor Number
i5-14400F
Lithography
Intel 7
Use Conditions
PC/Client/Tablet
CPU Specifications
Total Cores
10
# of Performance-cores
6
# of Efficient-cores
4
Total Threads
16
Max Turbo Frequency
4.7 GHz
Performance-core Max Turbo Frequency
4.7 GHz
Efficient-core Max Turbo Frequency
3.5 GHz
Performance-core Base Frequency
2.5 GHz
Efficient-core Base Frequency
1.8 GHz
Cache
20 MB Intel Smart Cache
Total L2 Cache
9.5 MB
Processor Base Power
65 W
Maximum Turbo Power
148 W
Supplemental Information
Marketing Status
Launched
Launch Date
Q1'24
Embedded Options Available
No
Memory Specifications
Max Memory Size (dependent on memory type)
192 GB
Memory Types
Up to DDR5 4800 MT/s
Up to DDR4 3200 MT/s
Max # of Memory Channels
2
Max Memory Bandwidth
76.8 GB/s
Expansion Options
Direct Media Interface (DMI) Revision
4.0
Max # of DMI Lanes
8
Scalability
1S Only
PCI Express Revision
5.0 and 4.0
PCI Express Configurations
Up to 1x16+4, 2x8+4
Max # of PCI Express Lanes
20
Package Specifications
Sockets Supported
FCLGA1700
Max CPU Configuration
1
Thermal Solution Specification
PCG 2020C
TJUNCTION
100°C
Package Size
45.0 mm x 37.5 mm
Advanced Technologies
Intel Gaussian & Neural Accelerator
3.0
Intel Thread Director
Yes
Intel Deep Learning Boost (Intel DL Boost) on CPU
Yes
Intel Speed Shift Technology
Yes
Intel Turbo Boost Technology
2.0
Intel Hyper-Threading Technology
Yes
Intel 64
Yes
Instruction Set
64-bit
Instruction Set Extensions
Intel SSE4.1, Intel SSE4.2, Intel AVX2
Idle States
Yes
Enhanced Intel SpeedStep Technology
Yes
Thermal Monitoring Technologies
Yes
Intel Volume Management Device (VMD)
Yes
Security & Reliability
Intel Standard Manageability (ISM)
Yes
Intel Control-Flow Enforcement Technology
Yes
Intel AES New Instructions
Yes
Secure Key
Yes
Intel OS Guard
Yes
Execute Disable Bit
Yes
Intel Boot Guard
Yes
Mode-based Execute Control (MBEC)
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
MSI PRO B760M-E
CHIPSET |
INTEL B760 |
---|---|
CPU |
Support Intel Core 14th/ 13th/ 12th Gen Processors, Intel Pentium Gold and Celeron ProcessorsLGA 1700 |
MEMORY |
2x DDR5, Maximum Memory Capacity 128GBMemory Support DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC)Max. overclocking frequency:• 1DPC 1R Max speed up to 6400+ MHz• 1DPC 2R Max speed up to 5600+ MHzSupports Intel XMP 3.0 OCSupports Dual-Controller Dual-Channel modeSupports non-ECC, un-buffered memory |
ONBOARD GRAPHICS |
1x HDMISupport HDMI 1.4 with HDR, maximum resolution of 4K 30Hz*1x VGASupport VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz |
SLOT |
1x PCI-E x16 slot1x PCI-E x1 slotPCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) |
STORAGE |
1x M.2M.2_1 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices4x SATA 6G* SATA5 will be unavailable when installing M.2 SATA SSD in the M2_1 slot. |
RAID |
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
USB |
4x USB 2.0 (Rear)4x USB 2.0 (Front)2x USB 5Gbps Type A (Rear)2x USB 5Gbps Type A (Front) |
LAN |
Realtek RTL8111H Gigabit LAN |
AUDIO |
Realtek ALC897 Codec7.1-Channel High Definition Audio |
INTERNAL IO |
1x Power Connector(ATX_PWR)1x Power Connector(CPU_PWR)1x CPU Fan2x System Fan2x Front Panel (JFP)1x Chassis Intrusion (JCI)1x Front Audio (JAUD)1x Com Port (JCOM)1x RGB LED connector(JRGB)1x TPM pin header(Support TPM 2.0)4x USB 2.0 ports2x USB 5Gbps Type A ports |
LED FEATURE |
4x EZ Debug LED |
BACK PANEL PORTS |
|
OPERATING SYSTEM |
Support for Windows 11 64-bit, Windows 10 64-bit |
PCB INFO |
mATX200mmx236.16mm |
RAM PATRIOT 8X2 3200 VIPER STEEL
Capacity: 16GB (2 x 8GB) DDR4
Kit; Base Frequency: PC4-17000 (2133MHz); Tested Frequency: PC4-
25600 (3200MHz); Tested Timings: 16-18-18-36; Voltage: 1.35V
5 RGB zones for fully customizable lighting
Compatible with leading motherboard partners' RGB Sync application;
XMP 2.0 support for automatic overclocking
Format: NON-ECC Unbuffered DIMM; pin out: 288-pin
Brand |
Patriot VIPER |
Model |
PVR416G320C6 |
Capacity |
16GB |
Base Frequency |
PC4-21300(2666MHz) |
Base Timings |
19-19-19-43 |
Tested Frequency |
PC4-25600 (3200MHz) |
Tested Timings |
16-20-20-40 |
Tested Voltage for Profile 1 |
1.35V |
