ASUS PRIME Z790M-PLUS D4 Motherboard
ASUS Prime series motherboards are expertly engineered to unleash the full potential of 13t Gen Intel Core Processors. Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options, PRIME Z790M-PLUS D4 provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features.
-
Intel LGA 1700 socket: Ready for 12th and 13th Gen Intel processors
-
Enhanced power solution: 16+1 DrMOS, ProCool connectors, chokes and durable capacitors for stable power delivery
-
Comprehensive cooling: Large VRM heatsinks, M.2 heatsinks, hybrid fan headers and Fan Xpert 4
-
Next-gen connectivity: DDR5 memory, PCIe 5.0, Intel 2.5 Gb Ethernet, USB 3.2 Gen2x2 Type-C, front panel USB 3.2 Gen 2 Type-C, Thunderbolt (USB4) header support, 4 PCIe 4.0 M.2
-
Exclusive AI & Memory technology: AI Cooling II, Two-Way AI Noise-Cancelation, ASUS Enhanced Memory Profile II and ASUS OptiMem II
-
PC DIY design: PCIe Slot Q-Release, M.2 Q-Latch, Q-LED Core, and SafeSlot
|
|
|
|
|---|---|---|
AI Cooling llAI Cooling II balances the thermals and acoustics of any build with a single click. A proprietary ASUS algorithm slashes unnecessary noise while running a quick stress test, and then it monitors CPU temperatures to dynamically adjust fans to optimal speeds. |
M.2 HeatsinksThree M.2 heatsinks cover four M.2 slots, warding off throttling that can occur with M.2 storage during sustained transfers.Removable captive screws reduce risk of drops or loss during heatsink removal. |
VRM Heatsinks and Thermal PadsThe extensive surface area of the massive heatsinks cover the VRMs and chokes to improve heat dissipation. Together with specially engineered thermal pads, they improve heat transfer from the MOSFETs and chokes for better cooling performance. |
|
|
|
|
|---|---|---|
Robust Power DesignStable power is essential to extract every last bit of performance out of Intel processors. The PRIME Z790M-PLUS D4 is geared to cater to the demands of these high-core-count CPUs.1. ProCool ConnectorsProprietary connectors augment the motherboard's link to the PSU with 8+8 pin connectors that pass 12 volts of power directly to the processors. Each jack features solid pins that can handle more current than hollow-pin connectors.2. 16 + 1 Teamed Power Stages16 + 1 power stages combine high-side and low-side MOSFETS and drivers ackages rated for 60 amperes each, delivering power, efficiency, stability and performance to latest Intel processors. |
AEMP II for Ultimate DDR5 PerformanceASUS Enhanced Memory Profile II (AEMP II) is an exclusive firmware feature for PMIC-restricted memory modules. AEMP II is based on a CPU and memory module’s ability to train the memory chips on your kit, and it presents an optimized clock speed that can effortlessly unleash performance.Built through a flexible training method, AEMP II makes it easy to not only tune the memory above baseline settings but also maintain the stability of system operations, whether getting the most out of an entry-level module or priming a high-speed kit for ultimate performance. |
Four M.2 slots (up to 64 Gbps)PRIME Z790M-PLUS D4 offers a total of four M.2 slots that support data-transfer speeds of up to 64 Gbps via PCIe 4.0, enabling quicker boot-up and app load times with OS or application drives. |
|
|
|
|
|---|---|---|
PCIe 5.0 SlotPCIe 5.0 offers twice the data transfer speed of PCIe 4.0, making it robust enough to handle new data-heavy tasks. PCIe 5.0 also brings other benefits, such as electrical changes to improve signal integrity, backward-compatible CEM connectors for add-in cards, and compatibility with previous versions of PCI Express. |
USB 3.2 Gen 2x2 Type-CA batch of USB ports support high-end rigs loaded with peripherals, including both front and rear USB Type-C connectors with ultrafast USB 3.2 Gen 2x2 for transmission speeds of up to 20 Gbps. |
Intel Core i5 14400F 20M Cache, up to 4.70 GHz processor
Code Name
Products formerly Raptor Lake
Vertical Segment
Desktop
Processor Number
i5-14400F
Lithography
Intel 7
Use Conditions
PC/Client/Tablet
CPU Specifications
Total Cores
10
# of Performance-cores
6
# of Efficient-cores
4
Total Threads
16
Max Turbo Frequency
4.7 GHz
Performance-core Max Turbo Frequency
4.7 GHz
Efficient-core Max Turbo Frequency
3.5 GHz
Performance-core Base Frequency
2.5 GHz
Efficient-core Base Frequency
1.8 GHz
Cache
20 MB Intel Smart Cache
Total L2 Cache
9.5 MB
Processor Base Power
65 W
Maximum Turbo Power
148 W
Supplemental Information
Marketing Status
Launched
Launch Date
Q1'24
Embedded Options Available
No
Memory Specifications
Max Memory Size (dependent on memory type)
192 GB
Memory Types
Up to DDR5 4800 MT/s
Up to DDR4 3200 MT/s
Max # of Memory Channels
2
Max Memory Bandwidth
76.8 GB/s
Expansion Options
Direct Media Interface (DMI) Revision
4.0
Max # of DMI Lanes
8
Scalability
1S Only
PCI Express Revision
5.0 and 4.0
PCI Express Configurations
Up to 1x16+4, 2x8+4
Max # of PCI Express Lanes
20
Package Specifications
Sockets Supported
FCLGA1700
Max CPU Configuration
1
Thermal Solution Specification
PCG 2020C
TJUNCTION
100°C
Package Size
45.0 mm x 37.5 mm
Advanced Technologies
Intel Gaussian & Neural Accelerator
3.0
Intel Thread Director
Yes
Intel Deep Learning Boost (Intel DL Boost) on CPU
Yes
Intel Speed Shift Technology
Yes
Intel Turbo Boost Technology
2.0
Intel Hyper-Threading Technology
Yes
Intel 64
Yes
Instruction Set
64-bit
Instruction Set Extensions
Intel SSE4.1, Intel SSE4.2, Intel AVX2
Idle States
Yes
Enhanced Intel SpeedStep Technology
Yes
Thermal Monitoring Technologies
Yes
Intel Volume Management Device (VMD)
Yes
Security & Reliability
Intel Standard Manageability (ISM)
Yes
Intel Control-Flow Enforcement Technology
Yes
Intel AES New Instructions
Yes
Secure Key
Yes
Intel OS Guard
Yes
Execute Disable Bit
Yes
Intel Boot Guard
Yes
Mode-based Execute Control (MBEC)
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
