OFFER 7-7 Bundle 4

OFFER 7-7 Bundle 4

 Intel Core i5 processor 14600K 24M Cache, up to 5.30 GHz

*Product Collection : intel core i5 processors (14th gen )

Vertical Segment : Desktop

Processor Number  : i5-14600K

Lithography  : Intel 7

Use Conditions  : PC/Client/Tablet, Workstation

*CPU Specifications

Total Cores  : 14

# of Performance-cores : 6

# of Efficient-cores : 8

Total Threads  : 20

Max Turbo Frequency  : 5.3 GHz

Performance-core Max Turbo Frequency  : 5.3 GHz

Efficient-core Max Turbo Frequency  : 4 GHz

Performance-core Base Frequency : 3.5 GHz

Efficient-core Base Frequency : 2.6 GHz

Cache  : 24 MB Intel Smart Cache

Total L2 Cache : 20 MB

Processor Base Power  : 125 W

Maximum Turbo Power  : 181 W

*Supplemental Information

Marketing Status : Launched

Launch Date  : Q4'23

Embedded Options Available  : No

*Memory Specifications

Max Memory Size (dependent on memory type)  : 192 GB

Memory Types

Up to DDR5 5600 MT/s
Up to DDR4 3200 MT/s

Max # of Memory Channels  : 2

Max Memory Bandwidth  : 89.6 GB/s

ECC Memory Supported  : Yes

*GPU Specifications

Processor Graphics  : Intel UHD Graphics 770

Graphics Base Frequency  : 300 MHz

Graphics Max Dynamic Frequency  : 1.55 GHz

Graphics Output  : eDP 1.4b, DP 1.4a, HDMI 2.1

Execution Units  : 32

Max Resolution (HDMI) : 4096 x 2160 @ 60Hz

Max Resolution (DP) : 7680 x 4320 @ 60Hz

Max Resolution (eDP - Integrated Flat Panel) : 5120 x 3200 @ 120Hz

DirectX* Support  : 12

OpenGL* Support  : 4.5

OpenCL* Support  : 3

Multi-Format Codec Engines  : 2

Intel Quick Sync Video  : Yes

Intel Clear Video HD Technology  : Yes

# of Displays Supported  : 4

Device ID : 0xA780

*Expansion Options

Direct Media Interface (DMI) Revision : 4.0

Max # of DMI Lanes : 8

Scalability : 1S Only

PCI Express Revision  : 5.0 and 4.0

PCI Express Configurations  : Up to 1x16+4, 2x8+4

Max # of PCI Express Lanes  : 20

*Package Specifications

Sockets Supported  : FCLGA1700

Max CPU Configuration : 1

Thermal Solution Specification  : PCG 2020A

T_JUNCTION  : 100°C

Package Size : 45.0 mm x 37.5 mm

*Advanced Technologies

Intel Gaussian & Neural Accelerator  : 3.0

Intel Thread Director  : Yes

Intel Deep Learning Boost (Intel DL Boost) on CPU  : Yes

Intel Speed Shift Technology  : Yes

Intel Turbo Boost Technology  : 2.0

Intel Hyper-Threading Technology  : Yes

Intel 64  : Yes

Instruction Set  : 64-bit

Instruction Set Extensions

Intel SSE4.1, Intel SSE4.2, Intel AVX2

Idle States  : Yes

Enhanced Intel Speed Step Technology  : Yes

Thermal Monitoring Technologies  : Yes

Intel Volume Management Device (VMD)  : Yes

*Security & Reliability

Intel Standard Manageability (ISM)  : Yes

Intel Control-Flow Enforcement Technology  : Yes

Intel AES New Instructions  : Yes

Secure Key  : Yes

Intel OS Guard : Yes

Execute Disable Bit   : Yes

Intel Boot Guard  : Yes

Mode-based Execute Control (MBEC)  : Yes

Intel Virtualization Technology (VT-x)   : Yes

Intel Virtualization Technology for Directed I/O (VT-d)  : Yes

Intel VT-x with Extended Page Tables (EPT) ; Yes

ZOTAC GAMING GeForce RTX 4060 Ti 8GB Twin Edge OC SPIDER-MAN Across the Spider-Verse Bundle

The ZOTAC GAMING GeForce RTX 4060 Ti 8GB Twin Edge OC is a compact and powerful graphics card, featuring the NVIDIA Ada Lovelace architecture and an aerodynamic-inspired design. With a reduced 2.2 slot size, it's an excellent choice for those who want to build a SFF gaming PC capable of smooth framerate and performance in the latest title releases.

This Spider-Man: Across the Spider-Verse inspired bundle includes a number of themed goodies, such as a themed magnetic backplate and custom fan emblems to make the Twin Edge OC extra stylish, as well as a tote bag and a set of decorative decals that fans are sure to love.

Feature Highlights:
- Powered by NVIDIA DLSS 3, ultra-efficient Ada Lovelace arch, and full ray tracing
- IceStorm 2.0 Advanced Cooling
- FREEZE Fan Stop, Active Fan Control
- Compact 2.2 Slot Footprint
- SPECTRA RGB Lighting
- Metal Backplate
- All-new FireStorm Utility

SPIDER-MAN: ACROSS THE SPIDER-VERSE INSPIRED HARDWARE BUNDLES

Power up your gaming experience with SPIDER-MAN: ACROSS THE SPIDER-VERSE limited-edition inspired hardware bundles, which come with exciting themed goodies to accompany you on your gaming journeys

• GPU : GeForce RTX 4060 Ti

• CUDA cores : 4352

• Video Memory : 8GB GDDR6

• Memory Bus : 128-bit

• Engine Clock : Boost: 2550MHz

• Memory Clock : 18 Gbps

• PCI Express : 4.0 x8

• Display Outputs

  3 x DisplayPort 1.4a (up to 7680x4320@60Hz)
  1 x HDMI Connector*
  *Supports 4K 120Hz HDR, 8K 60Hz HDR, and Variable Refresh Rate as specified in the HDMI 2.1a Specification

• HDCP Support : 2.3

• Multi Display Capability : Quad Display

• Recommended Power Supply : 500W

• Power Consumption : 160W

• Power Input : 1 x 8-pin PCIe

• DirectX : 12 Ultimate

• OpenGL :4.6

• Cooling : IceStorm 2.0

• Slot Size : 2.2 slot

• SLI : N/A

• Supported OS : Windows 11 / 10 (64-bit, v1809 November 2018 or later)

• Card Length : 225.5mm x 123.2mm x 40.1mm / 8.9" x 4.9" x 1.6"

• Accessories

  User Manual
  Themed Magnetic Backplate (approx. 3mm thick)
  Themed Fan Emblem Badges
  Decals
  Tote Bag

TeamGroup T-Force Vulcan Z DDR4 Desktop RAM

Memory Size: 8GB/16GB

Memory Type : DDR4

Module Type: DIMM

Memory Speed: 3200MHZ/3600MHZ

CL-tRCD-tRP-tRAS

CL16-18-18-38

Data transfer bandwidth: 24,000 MB/s (PC4 24000)

Heat Sink: Aluminum heat spreader

Working voltage: 1.35V

Lexar NM620 M.2 2280 Internal SSD

With speeds of up to 3300MB/s read, enjoy 6x the speed of SATA SSDs3. The NM620 puts you in the computing fast lane and offers impressive performance for demanding creative workstations and gaming experiences.

 Features LDPC for added reliability

Low-Density Parity Check (LDPC) technology makes data transfers more reliable than ever by fixing data errors before they have a chance to slow you down.

Unlike traditional hard disk drives, the NM620 SSD has no moving parts, so it’s built to last. On top of that, it’s also shock and vibration resistant2, making it one robust and reliable SSD.

Efficient

Reduced power consumption and cooler operation makes the battery life last longer than a traditional hard drive

Case Antec AX61 Elite 4Fan 120M ARGB

• Unique Design & Powerful Heat Dissipation.

• High-Airflow Mesh Front Panel.

• Pre-Installed 4 x 120mm ARGB Fans.

• In Sync with the Motherboard for ARGB Lighting.

• Up to 8 x 120mm Fans Simultaneously.

XIGMATEK AIR KILLER S AIR CPU COOLER

EN47901 EAN:4713436747901
Air Killer S (Black, X22C, Black Top Cover, Reinforced Plastic Steel Backplate)

EN47932 EAN:4713436747932
Air Killer S Arctic (White, X22C, White Top Cover, Reinforced Plastic Steel Backplate) )

• Ultra-Efficient Thermal Heat-Pipe and Patented Xigmatek H.D.T. Technology
• High Performance Heat Dissipation & Air Flow
• Support Latest 12th Gen Intel Core Desktop Processor Family
• Luxurious Top Cover Aluminum X Logo Badgeand
• Long Life Hydraulic Bearing & MTTF Up to 50,000 Hours
• Silent Operation at ≤25.3 dBA
• Support of Additional 120mm Fan (Support Up to TDP 190W)
• Non-Interference Between Memory Modules and CPU Cooler

*Product Name : AIR-KILLERS/AIR-KILLER S ARCTIC

*CPU Support

Intel: LGA 2066/2011-V3/2011/1700/115x/1200

AMD: AM4/AM3+/AM3

*Product Dimensions : 128x76x160mm (LxWxH)

*Heat Sink Dimensions : 128x50x155mm (LxWxH)

*Heat Sink Material : 4pcs Heat Pipes / Aluminum Fins

*Heat Pipe Dimensions : 06 mm

*TDP : 160W

Fan Dimensions : 120 x 120 x 25 mm

Fan Speed : 800-1,800 RPM (PWM) + 10%

Fan Bearing : Long Life Hydraulic Bearing

Fan LED Color : X22C Rainbow LED Fan

Fan Air Flow : 82.2 CFM(Max)

Fan Air Pressure : 2.55 mm-H2O(Max)

Fan MTTF : 50,000 hours

Fan Noise Level : <25.3 dBA

Fan Connector : 4-Pin (PWM)

Fan Rated Voltage : 12 VDC

Fan Rated Current : 0.24A

Fan Power Consumption : <2.8W
