ARCTIC Liquid Freezer III 240 CPU AIO Water Cooler

ARCTIC Liquid Freezer III 240

Dimensions

• Product Dimensions: 12.48" (L) x 5.51" (W) x 2.56" (H)

General Information

• Brand: ARCTIC

• Power Connector Type: 4-Pin

• Voltage: 12 Volts

• Wattage: 4.2 watts

• Cooling Method: Water

• Compatible Devices:

  • Intel Sockets: LGA1851, LGA1700

  • AMD Sockets: AM5, AM4

Materials

• Radiator Material: Aluminium

• Cold Plate Material: Copper with Micro Skived Fins

Performance

• Maximum Rotational Speed: 1700 RPM

• Air Flow Capacity: 72.8 Cubic Feet Per Minute (CFM)

Compatibility

• Intel Sockets: LGA1851, LGA1700

• AMD Sockets: AM5, AM4

Thermal Specifications

• PI | NNPI: 308 | 230

• Thermal Interface Material (TIM): MX-6 (0.8 g)

Warranty

• Duration: 6 Years

Environmental Conditions

• Operating Ambient Temperature: 0°C — 40°C

Weight

• Product Weight: 1490 g

All-In-One Connector

• Type: 4-Pin PWM Connector

• Split Connector: 3x 4-Pin PWM Connector

Pump Specifications

• Speed: 800—2800 RPM (PWM controlled)

• Current | Voltage: 0.35 A | 12 V DC

• Cold Plate: Copper with Micro Skived Fins

Tubing

• Length: 450 mm

• Diameter:

  • Outer: 12.4 mm

  • Inner: 6.0 mm

Radiator

• Material: Aluminium

• Dimensions: 277 mm (L) x 120 mm (W) x 38 mm (H)

VRM Module

• Fan Speed: 400—2500 RPM (PWM controlled)

• Current | Voltage: 0.05 A | 12 V DC

Radiator Fans

• Fans: 2x P12 PWM

• Speed: 200—1800 RPM

• Air Flow: 56.30 CFM | 95.65 m³/h

• Static Pressure: 2.20 mmH2O

• Bearing: Fluid Dynamic Bearing

• Current | Voltage: 0.10 A | 12 V DC

• Cable Length: 40 mm

• Connector: 4-Pin PWM Connector

Packaging

• Width: 171 mm

• Height: 142 mm

• Length: 294 mm

• Weight: 1.9 kg

Identifiers

• EAN: 4895213704465

• UPC: 840033402231
