Part No
|
90NR0CG1-M002S0
|
Model Name
|
G834JY-N6033W
|
TTV
|
2023-08-11
|
End of Production
|
2023-12-03
|
EAN Code
|
4711387028339
|
UPC Code
|
197105028333
|
WEEE
|
3.898
|
BASE UNIT
|
VSNR0CG1-BU1100
|
|
|
Marketing Name
|
ROG Strix SCAR 18
|
Color
|
Black
|
Dimension (W x D x H)
|
39.9 x 29.4 x 2.31 ~ 3.08 cm (15.71" x 11.57" x 0.91" ~ 1.21")
|
Weight
|
3.10 Kg (6.83 lbs)
|
Processor
|
13th Gen Intel® Core™ i9-13980HX Processor 2.2 GHz (36M Cache, up to 5.6 GHz, 24 cores: 8 P-cores and 16 E-cores)
|
Chipset
|
Mobile Intel® HM770 Express Chipsets
|
Discrete/Optimus
|
MUX Switch + NVIDIA® Advanced Optimus
|
Graphic
|
NVIDIA® GeForce RTX™ 4090 Laptop GPU
|
Graphic Wattage
|
ROG Boost: 2090MHz* at 175W (2040MHz Boost Clock+50MHz OC, 150W+25W Dynamic Boost)
|
Graphic Memory
|
16GB GDDR6
|
IGPU
|
Intel® UHD Graphics
|
Panel Size
|
18-inch
|
Resolution
|
QHD+ 16:10 (2560 x 1600, WQXGA)
|
Refresh Rate
|
240Hz
|
Response Time (G2G)
|
3ms
|
Viewing Angle
|
85/85/85/85
|
Panel Tech
|
IPS-level
|
Brightness
|
500
|
Contrast
|
1000:1
|
DCI-P3 %
|
100.00%
|
Anti glare
|
Anti-glare display
|
Adaptive-Sync technology
|
G-Sync
|
Pantone
|
Pantone Validated
|
Nebula Display
|
ROG Nebula Display
|
Support Dolby Vision HDR
|
Yes
|
On board memory
|
N/A
|
DIMM Memory
|
16GB DDR5-4800 SO-DIMM *2
|
Total System Memory
|
DDR5 32GB
|
Memory Slot
|
2x SO-DIMM slots
|
Memory Max.
|
64GB
|
Multi-channel memory technology
|
Support dual channel memory
|
System Storage Installed
|
1TB + 1TB PCIe® 4.0 NVMe™ M.2 Performace SSD (RAID 0)
|
M.2 slots support either SATA or NVMe
|
2
|
M.2 SSD Support List
|
512GB/1TB/2TB G4x4 PCIe SSD
|
Expansion Slot (includes used)
|
2x DDR5 SO-DIMM slots
2x PCIe
|
LAN
|
10/100/1000/2500 Mbps
|
On board Wireless
|
Wi-Fi 6E(802.11ax) (Triple band) 2*2 + Bluetooth® 5.2 Wireless Card (*Bluetooth® version may change with OS version different.)
|
Wi-Fi/Bluetooth
|
Wi-Fi 6E(802.11ax) (Triple band) 2*2 + Bluetooth® 5.3 Wireless Card (*Bluetooth® version may change with OS version different.)
|
I/O Ports
|
1x 2.5G LAN port
1x Thunderbolt™ 4 support DisplayPort™ / G-SYNC
1x USB 3.2 Gen 2 Type-C support DisplayPort™ / power delivery / G-SYNC
2x USB 3.2 Gen 2 Type-A
|
Display output
|
1x HDMI 2.1 FRL
|
Audio
|
1x 3.5mm Combo Audio Jack
|
Webcam
|
720P HD camera
|
Mic
|
Built-in array microphone
|
Keyboard Type
|
Backlit Chiclet Keyboard Per-Key RGB
|
NumberPad
|
N/A
|
Aura Sync
|
Yes
|
Speakers
|
4-speaker system with Smart Amplifier Technology
|
Audio Tech
|
AI noise-canceling technology
Dolby Atmos
Hi-Res certification
Smart Amp Technology
|
Operating System
|
Windows 11 Home
|
Antivirus
|
McAfee® 30 days free trial
|
Security
|
BIOS Administrator Password and User Password Protection
Trusted Platform Module (Firmware TPM)
|
Battery
|
90WHrs, 4S1P, 4-cell Li-ion
|
Fast charging
|
Recharge from 0-50% in 30 minutes
|
Power
|
ø6.0, 330W AC Adapter, Output: 20V DC, 16.5A, 330W, Input: 100~240C AC 50/60Hz universal
|
Bundled Peripherals
|
ROG backpack
Marketing Giveaway (1 Customizable Armor Cap)
|
Additional Accessories
|
ROG Gladius III Mouse P514
|
Reparability Index (for FR)
|
8.6
|
|
|
|
|
|
|
|
|
|
|
