BenQ Projector LU710- Laser - 4000 ANSI Lumens - WUXGA - 2HDMI-USB Type A-PC Input-D sub-Speaker. (x2), 10W

BenQ Projector LU710- Laser - 4000 ANSI Lumens - WUXGA - 2HDMI-USB Type A-PC Input-D sub-Speaker. (x2), 10W

Optical

Throw Ratio

1.13 ~ 1.46

Zoom Ratio

1.3x

Lens

F/# = 1.94 ~ 2.07,f = 11.9 ~ 15.5 mm

Projection Offset (Full-Height)

100%

Keystone Adjustment

2D, Vertical ± 30 degrees; Horizontal ± 30 degrees


Rec. 709 Coverage

92%

Picture Modes

3D, Bright, Infographic, Presentation, sRGB, User 1, User 2, Video

Compatibility

Input Lag

34 ms (1080p@60Hz)

Resolution Support

VGA(640 x 480) to WUXGA_RB(1920 x 1200) *RB=Reduced blanking

Horizontal Frequency

15K~102KHz

Vertical Scan Rate

23~120Hz

I/O Interface

PC in (D-sub 15pin)

(x1), PC in-1

Monitor out (D-sub 15pin)

(x1)

Composite Video in (RCA)

(x1)

Component Video in (3RCA)

(x1)

HDMI in

(x2), HDMI-1 (1.4a/HDCP1.4), HDMI-2 (1.4a/HDCP1.4)

LAN (RJ45)

(x1)

USB Type A

(x1), USB Type A-1 (2.0/Power Supply1.5A/Service)

RS232 in (DB-9pin)

(x1)

DC 12V Trigger (3.5mm Jack)

(x1)

Audio

Speaker

(x2), 10W

Audio in (3.5mm Mini Jack)

(x1), 1

Audio out (3.5mm Mini Jack)

(x1), 1

Environment

Operating Temperature

0~40℃

Power Supply

AC 100 to 240 V, 50/60 Hz

Typical Power Consumption (110V)

Max 340W/ Normal 290W/ Eco 190W

Stand-by Power Consumption

<0.5W

Network Stand-by Power Consumption

<2W

Acoustic Noise (Typ./Eco.)(dB)

34/29 dB

Accessories

Remote Control w/ Battery

RCE016

Power Cord (by region)

x1 (1.8M)

HDMI cable

(Standard), Yes, 1.8m

3D Glasses

(Optional), DGD5

Quick Start Guide

1 (21L)

Warranty Card (by region)

Yes

Anti-dust Filter

(Optional), Yes

Universal Ceiling Mount

Yes, CMG3

InstaShow Package

HDMI cable

(Standard), Yes, 1.8m

InstaShow Host

LAN (RJ45)

(x1)

Dimension & Weight

Projection System
