Bundle Consul 5 - AMD RYZEN 5 7600X - RAM LEXAR ARES 16GB - SSD LEXAR NM620 1TB - RTX 4070 TI 12GB

Bundle Consul 5 - AMD RYZEN 5 7600X - RAM LEXAR ARES 16GB - SSD LEXAR NM620 1TB - RTX 4070 TI 12GB



AMD Ryzen 5 7600X 6-Core, 12-Thread Unlocked Desktop Processor



General Specifications

Connectivity

Graphics Capabilities

Product IDs



ASUS TUF Gaming GeForce RTX 4070 Ti 12GB GDDR6X

• Powered by NVIDIA DLSS3, ultra-efficient Ada Lovelace arch, and full ray tracing.

• 4th Generation Tensor Cores: Up to 4x performance with DLSS 3 vs. brute-force rendering

• 3rd Generation RT Cores: Up to 2X ray tracing performance

• Axial-tech fans scaled up for 21% more airflow

• Dual ball fan bearings last up to twice as long as conventional designs

• Military-grade capacitors rated for 20K hours at 105C make the GPU power rail more durable

• Metal exoskeleton adds structural rigidity and vents to increase heat reliability

• Auto-Extreme precision automated manufacturing for higher reliability

• GPU Tweak III software provides intuitive performance tweaking, thermal controls, and system monitoring

Graphic Engine : NVIDIA GeForce RTX 4070 Ti

Engine Clock : OC mode: 2640 MHz

CUDA Core : 7680

Memory Speed : 21 Gbps

Memory Interface : 192-bit

Resolution : Digital Max Resolution 7680 x 4320

Interface

Maximum Display Support : 4

NVlink/ Crossfire Support : No

Accessories

Software

Dimensions

Recommended PSU

Power Connectors

Slot

AURA SYNC



ASUS TUF GAMING B650M-E



ASUS TUF GAMING B650M-E takes all the essential elements of the latest AMD Ryzen 7000-series processors and combines them with game-ready features and proven durability. Engineered with military-grade components, an upgraded power solution and a comprehensive cooling system, this motherboard goes beyond expectations with rock-solid and stable performance for marathon gaming. TUF GAMING motherboards also undergo rigorous endurance testing to ensure that they can handle conditions where others may fail. Aesthetically, this model incorporates rugged off-black and geometric design elements to reflect the dependability and stability that defines the TUF GAMING series.

INTELLIGENT CONTROL

Comprehensive controls form the foundation of the ASUS TUF GAMING series. The TUF GAMING B650 motherboard packs flexible tools to tune every aspect of your system, enabling performance tweaks to perfectly match the way you work to maximize productivity.

CPU Performance Boost

AMD Precision Boost Overdrive(PBO) pushes the CPU current and voltage budget to opportunistically increase performance. By aggressively tuning the PBO parameters, AMD‘s algorithm can leverage the motherboard’s robust power solution to ramp up performance even higher.

ROCK-SOLID PERFORMANCE

With upgraded power delivery and comprehensive cooling options to fuel AMD's latest CPUs, plus support for faster memory and storage, TUF GAMING B650 motherboards are the perfect foundation for your next high-core-count AMD battle rig.

8(60A)+2(60A)+1 Power Stages

8(60A)+2(60A)+1 power stages are rated to handle up to 60 amperes, combining high-side and low-side MOSFETS and drivers into a single package to deliver power, efficiency and stable performance for all compatible AMD processors.

EASY PC DIY

The TUF GAMING line offers easy setup for all builders. The TUF GAMING Alliance ecosystem grants compatibility, while Armoury Crate has Fan Xpert 2+, hardware info, Two-Way AI Noise Cancelation, RGB options and peripheral settings. This platform has intuitive tools to build and optimize dream rigs.

Build With Confidence

TUF GAMING Alliance is a collaboration between ASUS and trusted PC component brands to ensure compatibility across a wide range of parts, such as PC cases, power supplies, CPU coolers, memory kits and more. With new partnerships and components being added regularly, the TUF GAMING Alliance will continue to grow even stronger.

IMMERSIVE GAMING

TUF GAMING B650 motherboards provide a feature-packed high-performance gaming package, with ultrafast networking for smoother online gameplay, pristine audio with positional cues for FPS Gaming, and onboard RGB lighting that syncs with attached gear to personalize your gaming atmosphere.





2.5 Gb Ethernet

2.5 Gb on-board Ethernet kicks your LAN connection up a notch with a bandwidth improvement of up to 2.5X. Using your existing LAN cable, you can take advantage this networking upgrade to experience smoother, lag-free gaming, immediately stream high-resolution videos and enjoy faster file transfers.

CPU

AMD Socket AM5 for AMD Ryzen 7000 Series Desktop Processors
Chipset

AMD B650

Memory

4 x DIMM slots, Max. 192GB, DDR5 7600+(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800 ECC and Non-ECC, Un-buffered Memory
Dual Channel Memory Architecture
Supports AMD Extended Profiles for Overclocking (EXPO)
OptiMem II
Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration,
 Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.

Graphics

2 x DisplayPort
1 x HDMI port
 specifications.
 Supports max. 8K@60Hz as specified in DisplayPort 1.4.
Supports 4K@60Hz as specified in HDMI 2.1.

Expansion Slots

AMD Ryzen 7000 Series Desktop Processors
1 x PCIe 4.0 x16 slot
AMD B650 Chipset
2 x PCIe 4.0 x1 slots

Storage

Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports
AMD Ryzen 7000 Series Desktop Processors
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
AMD B650 Chipset
4 x SATA 6Gb/s ports
AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/10 and SATA RAID 0/1/10.

Ethernet

1 x Realtek 2.5Gb Ethernet
TUF LANGuard

USB

Rear USB (Total 8 ports)
2 x USB 3.2 Gen 2 (10G) ports (1 x Type-A + 1 x USB Type-C)
2 x USB 3.2 Gen 1 (5G) ports (2 x Type-A)
4 x USB 2.0 ports (4 x Type-A)
Front USB (Total 7 ports)
1 x USB 3.2 Gen 1 (5G) connector (supports USB Type-C)
1 x USB 3.2 Gen 1 (5G) header supports 2 additional USB 3.2 Gen 1 ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports

Audio

Realtek 7.1 Surround Sound High Definition Audio CODEC*
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback"
Audio Features
- Audio Shielding
- Premium audio capacitors
- Dedicated audio PCB layers
* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.

Back Panel I/O Ports

2 x USB 3.2 Gen 2 (10G) ports (1 x Type-A + 1 x USB Type-C)
2 x USB 3.2 Gen 1 (5G) ports (2 x Type-A)
4 x USB 2.0 ports (4 x Type-A)
2 x DisplayPort
1 x HDMI port
1 x Realtek 2.5Gb Ethernet port
3 x Audio jacks
1 x BIOS FlashBack  button
1 x PS/2 Keyboard/Mouse combo port

Internal I/O Connectors

Fan and Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
2 x 4-pin Chassis Fan headers
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
1 x 4-pin +12V Power connector
Storage related
2 x M.2 slots (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen 1 (5G) connector (supports USB Type-C^® )
1 x USB 3.2 Gen 1 (5G) header supports 2 additional USB 3.2 Gen 1 ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
Miscellaneous
3 x Addressable Gen 2 headers
1 x Aura RGB header
1 x Clear CMOS header
1 x COM Port header
1 x Front Panel Audio header (AAFP)
1 x 20-3 pin System Panel header with Chassis intrude function

Special Features

Software Features

BIOS

256 Mb Flash ROM, UEFI AMI BIOS

Manageability

WOL by PME, PXE

Accessories

Operating System

Windows 11, Windows 10 64-bit

Form Factor



Lexar NM620 M.2 2280 Internal SSD



Weight	1 kg
Capacity	1TB, 256GB, 2TB, 512GB
brands	Lexar





With speeds of up to 3300MB/s read, enjoy 6x the speed of SATA SSDs3. The NM620 puts you in the computing fast lane and offers impressive performance for demanding creative workstations and gaming experiences.



 Features LDPC for added reliability

Low-Density Parity Check (LDPC) technology makes data transfers more reliable than ever by fixing data errors before they have a chance to slow you down.



Unlike traditional hard disk drives, the NM620 SSD has no moving parts, so it’s built to last. On top of that, it’s also shock and vibration resistant2, making it one robust and reliable SSD.

Efficient

Reduced power consumption and cooler operation makes the battery life last longer than a traditional hard drive



Lexar Ares 16GB (1x16GB) DDR5 SDRAM UDIMM Desktop Memory 4800 MHz



DEEPCOOL CC560  Case Tempered Glass, ABS Mid-Tower Computer Case/Gaming Cabinet - Black | Support - Mini-ITX/Micro-ATX/ATX | Pre-Installed 3 x 120mm Fans in Front and 1 x 120mm Fan in Rear





Evga ATX 700W GD 80 Plus Gold 100-GD-0700-V2 Power Supply

Category	Desktop
Subcategory	Power Supply
Brand	EVGA
Model	100-GD-0700-V2





DeepCool GAMMAXX AG400 plus CPU Air Cooler 220w TDP 6mm x 4 Nickel Plated Copper Heat Pipes CPU Cooler with 120mm Fan PWM 2000RPM 75.89CFM for Intel LGA 1700/1200/1151/1150/1155 AMD AM5/AM4

The DeepCool AG400 PLUS is a single tower 120mm CPU cooler that builds upon our legacy for high-quality cooling performance but stripped down for a streamlined and efficient package.

STELLAR THERMAL PERFORMANCE Enjoy better system performance by keeping things cool with up to 220W of heat dissipation power featuring four direct touch heat pipes that rapidly draw heat away from the CPU

BALANCED BIDIRECTIONAL HEAT PIPE TECHNOLOGY

By optimizing the internal capillary structure and injecting a precise amount of liquid, the heat pipe achieves the best heat dissipation performance regardless of whether the cooler is in a vertical or horizontal case. This perfect ratio facilitates a highly efficient phase change throughout the heat pipe and achieves lower thermal resistance over a wide TDP range.

SIMPLE AND SECURE The included mounting brackets support both Intel and AMD platforms with an easy five-step installation process that maintains great contact pressure. The offset design of the heat pipes ensures that the cooler can be installed with the fan already attached

Product Dimensions	125×107×150 mm
Heatsink Dimensions	120×92×150 mm
Net Weight	748 g
Heatpipe	Ø6 mm×4 pcs
Fan Dimensions	120×120×25 mm
Fan Speed	500~2000 RPM±10%
Fan Airflow	75.89 CFM
Fan Air Pressure	2.53 mmAq
Fan Noise	≤31.6 dB(A)

Fan Connector	4-pin PWM
Bearing Type	Hydro Bearing
Fan Rated Voltage	12 VDC
Fan Rated Current	0.17 A
Fan Power Consumption	2.04 W
EAN	6933412727767
P/N	R-AG400-BKNNMD-G
