BUNDLE 9-9 OFFER 2 RYZEN 5 7500F - RAM 16GB 4800MHZ SAMSUNG - HIKSEMI SSD NVME 256 - PNY 4060TI 16GB

BUNDLE 9-9 OFFER 2 RYZEN 5 7500F - RAM 16GB 4800MHZ SAMSUNG - HIKSEMI SSD NVME 256 - PNY 4060TI 16GB

AMD Ryzen 5 7500F, 6C/12T, 3.70-5.00GHz, tray

Platform : Desktop

Market Segment : Enthusiast Desktop

Product Family : AMD Ryzen Processors

Product Line : AMD Ryzen 5 Desktop Processors

AMD PRO Technologies : No

Consumer Use : Yes

Regional Availability : Global

Former Codename : "Raphael AM5"

Architecture : "Zen 4"

# of CPU Cores :6

Multithreading (SMT) : Yes

# of Threads : 12

Max. Boost Clock : Up to 5.0GHz

Base Clock : 3.7GHz

L1 Cache : 384KB

L2 Cache : 6MB

L3 Cache : 32MB

Default TDP : 65W

Processor Technology for CPU Cores : TSMC 5nm FinFET

Processor Technology for I/O Die : TSMC 6nm FinFET

CPU Compute Die (CCD) Size : 71mm²

I/O Die (IOD) Size : 122mm²

Package Die Count : 2

Unlocked for Overclocking : Yes

AMD EXPO Memory Overclocking Technology : Yes

Precision Boost Overdrive :Yes

Curve Optimizer Voltage Offsets : Yes

AMD Ryzen Master Support : Yes

CPU Socket : AM5

Supporting Chipsets

A620

X670E

X670

B650E

B650

CPU Boost Technology : Precision Boost 2

Instruction Set : x86-64

Supported Extensions : AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64

Thermal Solution (PIB) : AMD Wraith Stealth

Thermal Solution (MPK) : AMD Wraith Stealth

Max. Operating Temperature (Tjmax) : 95°C

Launch Date : 7/22/2023

*OS Support

Windows 11 - 64-Bit Edition

Windows 10 - 64-Bit Edition

RHEL x86 64-Bit

Ubuntu x86 64-Bit

*Operating System (OS) support will vary by manufacturer.

Connectivity

USB Type-C Support : Yes

Native USB 3.2 Gen 2 (10Gbps) Ports : 4

Native USB 3.2 Gen 1 (5Gbps) Ports : 0

Native USB 2.0 (480Mbps) Ports : 1

Native SATA Ports : 0

PCI Express Version : PCIe 5.0

Native PCIe Lanes (Total/Usable) : 28 / 24

Additional Usable PCIe Lanes from Motherboard

AMD X670E

12x Gen4

AMD X670 : 12x Gen4

AMD B650E : 8x Gen4

AMD B650 : 8x Gen4

AMD A620 : 4x Gen3

NVMe Support : Boot, RAID0, RAID1, RAID10

System Memory Type : DDR5

Memory Channels : 2

Max. Memory : 128GB

System Memory Subtype : UDIMM

Max Memory Speed  : 2x1R

DDR5-5200 : 2x2R

DDR5-5200 : 4x1R

DDR5-3600 : 4x2R

DDR5-3600

ECC Support : Yes (Requires mobo support)

Graphics Capabilities

Integrated Graphics  : No

Graphics Model

Discrete Graphics Card Required

Product IDs

Product ID Tray : 100-000000597

Product ID MPK : 100-100000597MPK

Key Features

Supported Technologies

AMD EXPO Technology

AMD Ryzen Technologies



GIGABYTE A620M H Motherboard



AMD Socket AM5：Supports AMD Ryzen 7000/ Ryzen 8000 Series Processors

Unparalleled Performance：5+2+2 Phases Digital VRM Solution

Dual Channel DDR5：2*SMD DIMMs with AMD EXPO & Intel XMP Memory Module Support

SuperSpeed Storage：PCIe 4.0 x4 M.2 Connector

EZ-Latch：PCIe x16 Slot with Quick Release Design

Fast Networks：GbE LAN

Extended Connectivity：DP, HDMI

Smart Fan 6：Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP

Q-Flash Plus：Update BIOS Without Installing the CPU, Memory and Graphics Card

5+2+2 Phases Digital VRM Solution with Low RDS(on) MOSFETs

GIGABYTE UD series motherboards use a 5+2+2 phases digital PWM + Low RDS(on) MOSFETs design to support AMD's new generation CPU by offering incredible precision in delivering power to the motherboard's most power-hungry and energy-sensitive components as well as delivering enhanced system performance and ultimate hardware scalability



GbE LAN with Bandwidth Management

GbE LAN features a network bandwidth management application which helps to improve network latency and maintain low ping times to deliver better responsiveness in crowded LAN environments

CPU

AMD Socket AM5, support for: AMD Ryzen 7000/ Ryzen 8000 Series Processors

Chipset

AMD A620

Memory

Support for DDR5 6400(OC)/6200(OC)/6000(OC)/5600(OC)/5200/4800/4400 MT/s memory modules

2 x DDR5 DIMM sockets supporting up to 96 GB (48 GB single DIMM capacity) of system memory

Dual channel memory architecture

Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules

(The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" for more information.)

Onboard Graphics

Integrated Graphics Processor:

1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz

• Support for DisplayPort 1.4 version.

1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

• Support for HDMI 2.1 version and HDCP 2.3.

** Support for native HDMI 2.1 TMDS compatible ports.

(Graphics specifications may vary depending on CPU support.)

Support for up to 3 displays at the same time

Audio

Realtek Audio CODEC

High Definition Audio

2/4/5.1/7.1-channel

• You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.

LAN

Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)

Expansion Slots

CPU:

1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16

Chipset:

1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1

Storage Interface

CPU:

1 x M.2 connector (Socket 3, M key, type 2580 PCIe 4.0 x4/x2 SSD support)

Chipset:

4 x SATA 6Gb/s connectors

RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices

RAID 0, RAID 1, and RAID 10 support for SATA storage devices

USB

CPU:

2 x USB 3.2 Gen 1 ports on the back panel

1 x USB 2.0/1.1 port on the back panel

Chipset:

2 x USB 3.2 Gen 1 ports available through the internal USB header

7 x USB 2.0/1.1 ports (3 ports on the back panel, 4 ports available through the internal USB headers)

Internal I/O Connectors

1 x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

1 x CPU fan header

2 x system fan headers

1 x addressable LED strip header

1 x RGB LED strip header

1 x M.2 Socket 3 connector

4 x SATA 6Gb/s connectors

1 x front panel header

1 x front panel audio header

1 x USB 3.2 Gen 1 header

2 x USB 2.0/1.1 headers

1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)

1 x Clear CMOS jumper

Back Panel Connectors

4 x USB 2.0/1.1 ports

1 x PS/2 keyboard/mouse port

1 x Q-Flash Plus button

2 x USB 3.2 Gen 1 ports

1 x DisplayPort

1 x HDMI port

1 x RJ-45 port

3 x audio jacks

I/O Controller

iTE® I/O Controller Chip

H/W Monitoring

Voltage detection

Temperature detection

Fan speed detection

Water cooling flow rate detection

Fan fail warning

Fan speed control

• Whether the fan speed control function is supported will depend on the fan you install.

BIOS

1 x 256 Mbit flash

Use of licensed AMI UEFI BIOS

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Unique Features

Support for GIGABYTE Control Center (GCC)

• Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.

Support for Q-Flash Plus

Support for Q-Flash

Bundled Software

Norton® Internet Security (OEM version)

LAN bandwidth management software

Operating System

Support for Windows 11 64-bit

Support for Windows 10 64-bit

Form Factor

Micro ATX Form Factor; 23.0cm x 22.5cm



GAMDIAS AURA GC2 Elite Version 2 ARGB 4xFARGB Mid Tower Gaming Case + PSU HELIOS E1-600W 80% Efficiency

• Mesh Front Panel

• Magnetic Dust Filter

• 4 Built-in 120mm Fixed RGB Fans

• Supports up to ATX motherboards

• Tool-Free Installation Tempered Glass Window

• PSU Shroud Included

• Compatible with 340mm GPU

• Meets 80% Efficiency

• 620mm EPS Cable

• Automatic Fan Speed Optimization

• Stealth Black

• Support C6/C7 Power States
