BUNDLE AORUS RETU
-
NVIDIA Ada Lovelace Streaming Multiprocessors:
Up to 2x performance and power efficiency
-
4th Generation Tensor Cores: Up to 4x performance with DLSS 3 vs. brute-force rendering
-
3rd Generation RT Cores: Up to 2X ray tracing performance
-
Powered by GeForce RTX 4090
-
Integrated with 24GB GDDR6X 384-bit memory interface
-
WINDFORCE cooling system
-
RGB Fusion
-
Dual BIOS
-
Protection metal back plate
-
Anti-sag bracket
-
Graphics Processing: GeForce RTX 4090
-
Core Clock: 2535 MHz (Reference Card: 2520 MHz)
-
CUDA Cores: 16384
-
Memory Clock: 21 Gbps
-
Memory Size: 24 GB
-
Memory Type: GDDR6X
-
Memory Bus: 384 bit
-
Card Bus: PCI-E 4.0 x 16
-
Digital max resolution: 7680×4320
-
Multi-view: 4
-
Card size: L=340 W=150.2 H=75.2 mm
-
PCB Form: ATX
-
DirectX: 12 Ultimate
-
OpenGL: 4.6
-
Recommended PSU: 1000W
-
Power Connectors: 16 pin*1
-
Output: DisplayPort 1.4 *3
HDMI 2.1 *1
-
Accessories
1. Quick guide
2. Warranty registration
3. Anti-sag bracket
4. Anti-sag bracket installation guide
5. One 16-pin to four 8-pin power adaptor
FRIENDLY PCB DESIGN
Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.
-
NVIDIA Ada Lovelace Streaming Multiprocessors:
Up to 2x performance and power efficiency
-
4th Generation Tensor Cores: Up to 4x performance with DLSS 3 vs. brute-force rendering
-
3rd Generation RT Cores: Up to 2X ray tracing performance
-
Powered by GeForce RTX 4090
-
Integrated with 24GB GDDR6X 384-bit memory interface
-
WINDFORCE cooling system
-
RGB Fusion
-
Dual BIOS
-
Protection metal back plate
-
Anti-sag bracket
-
-
LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel Core, Pentium Gold and Celeron Processors*
-
L3 cache varies with CPU
-
Chipset
-
Intel Z790 Express Chipset
-
Memory
-
Support for DDR5 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 memory modules
-
4 x DDR5 DIMM sockets supporting up to 192 GB (48 GB single DIMM capacity) of system memory
-
Dual channel memory architecture
-
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
-
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
-
Support for Extreme Memory Profile (XMP) memory modules
(The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules,
-
Onboard Graphics
Integrated Graphics Processor-Intel HD Graphics support:
-
1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
* Support for DisplayPort 1.2 version and HDCP 2.3
(Graphics specifications may vary depending on CPU support.)
-
Audio
-
Realtek ALC1220-VB CODEC
* The front panel line out jack supports DSD audio.
-
ESS ES9118 DAC chip
-
Support for DTS:X Ultra
-
High Definition Audio
-
2/4/5.1-channel
* You can change the functionality of an audio jack using the audio software. To configure 5.1-channel audio, access the audio software for audio settings.
-
Support for S/PDIF Out
-
LAN
-
Marvell AQtion AQC113C 10GbE LAN chip
(10 Gbps/5 Gbps/2.5 Gbps/1 Gbps/100 Mbps)
-
Wireless Communication module
Intel Killer Wi-Fi 6E AX169
-
WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
-
BLUETOOTH 5.3
-
Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
(Actual data rate may vary depending on environment and equipment.)
-
Expansion Slots
CPU:
-
1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16)
* The PCIEX16 slot shares bandwidth with the M2C_CPU connector. The PCIEX16 slot operates at up to x8 mode when a device is installed in the M2C_CPU connector.
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
Chipset:
-
1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4)
-
1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x1 (PCIEX1)
-
Storage Interface
CPU:
-
1 x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 5.0 x4/x2 SSD support) (M2C_CPU)
-
1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
Chipset:
-
1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB)
-
1 x M.2 connector (Socket 3, M key, type 2280/2260 PCIe 4.0 x4/x2 SSD support) (M2P_SB)
-
1 x M.2 connector (Socket 3, M key, type 2280/2260 SATA and PCIe 4.0 x4/x2 SSD support) (M2M_SB)
-
4 x SATA 6Gb/s connectors
RAID 0, RAID 1, RAID5, and RAID 10 support for NVMe SSD storage devices
RAID 0, RAID 1, RAID5, and RAID 10 support for SATA storage devices
-
USB
Chipset:
-
3 x USB Type-C ports, with USB 3.2 Gen 2x2 support (2 ports on the back panel, 1 port available through the internal USB header)
Chipset+2 USB 3.2 Gen 2 Hubs:
-
1 x USB Type-C port on the back panel, with USB 3.2 Gen 1 support
-
7 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
Chipset+2 USB 3.2 Gen 1 Hubs:
-
8 x USB 3.2 Gen 1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
Chipset+USB 2.0 Hub:
-
4 x USB 2.0/1.1 ports available through the internal USB headers
-
Internal I/O Connectors
-
1 x 24-pin ATX main power connector
-
2 x 8-pin ATX 12V power connectors
-
1 x CPU fan header
-
1 x water cooling CPU fan header
-
4 x system fan headers
-
4 x system fan/water cooling pump headers
-
2 x addressable LED strip headers
-
2 x RGB LED strip headers
-
5 x M.2 Socket 3 connectors
-
4 x SATA 6Gb/s connectors
-
1 x front panel header
-
1 x front panel audio header
-
1 x USB Type-C header, with USB 3.2 Gen 2x2 support
-
2 x USB 3.2 Gen 1 headers
-
2 x USB 2.0/1.1 headers
-
1 x noise detection header
-
2 x Thunderbolt™ add-in card connectors
-
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
-
1 x power button
-
1 x reset button
-
1 x reset jumper
-
1 x Clear CMOS jumper
-
2 x temperature sensor headers
-
Voltage Measurement Points
-
Back Panel Connectors
-
1 x Q-Flash Plus button
-
1 x Clear CMOS button
-
2 x SMA antenna connectors (2T2R)
-
1 x DisplayPort
-
1 x USB Type-C port, with USB 3.2 Gen 1 support
-
2 x USB Type-C ports, with USB 3.2 Gen 2x2 support
-
7 x USB 3.2 Gen 2 Type-A ports (red)
-
4 x USB 3.2 Gen 1 ports
-
1 x RJ-45 port
-
1 x optical S/PDIF Out connector
-
2 x audio jacks
-
I/O Controller
-
iTE I/O Controller Chip
-
H/W Monitoring
-
Voltage detection
-
Temperature detection
-
Fan speed detection
-
Water cooling flow rate detection
-
Fan fail warning
-
Fan speed control
* Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.
-
Noise detection
-
BIOS
-
1 x 256 Mbit flash
-
Use of licensed AMI UEFI BIOS
-
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
-
Unique Features
-
Support for GIGABYTE Control Center (GCC)
* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
-
Support for Q-Flash
-
Support for Q-Flash Plus
-
Support for Smart Backup
-
Bundled Software
-
Norton Internet Security (OEM version)
-
LAN bandwidth management software
-
Operating System
-
Support for Windows 11 64-bit
-
Support for Windows 10 64-bit
-
Form Factor
-
E-ATX Form Factor; 30.5cm x 26.0c
-
Case Form Factor Full Tower
-
M/B Type Mini ITX / Micro ATX / ATX / E-ATX
-
Color Black
-
Materials Aluminum, Steel, Plastic, Glass
-
Dimensions H=714 W=301 D=671 mm (Within ± 1% error)
-
Expansion slots 8 + 2 (Requires PCI-E Riser Cable)
-
5.25" Drive Bays None
-
Case Form Factor
Full Tower
-
M/B Type
Mini ITX / Micro ATX / ATX / E-ATX
-
Color
Black
-
Materials
Aluminum, Steel, Plastic, Glass
-
Dimensions
H=714 W=301 D=671 mm (Within ± 1% error)
-
Expansion slots
8 + 2 (Requires PCI-E Riser Cable)
-
5.25" Drive Bays
None
-
3.5“/2.5” Drive Bays
4
-
2.5" Drive Bays
6
-
I/O Panel
USB 3.1 Gen-2 Type-C x1
USB 3.0 x4
HDMI x1
RGB SW Button
Fan Speed Button
Audio In & Out (supports AC97 /HD Audio)
-
Pre-installed Fan
Front : 120mm x3 (PWM)
Rear : 120mm x2 (ARGB&PWM)
-
Fan Support
Front : 120mm x3 / 140mm x3
Top : 120mm x3 / 140mm x3
Rear : 120mm x2 / 140mm x1
-
Radiator Support
Front : Max 360mm
Top : Max 420mm
Rear : Max 140mm
-
Power Supply Type
Standard ATX (Not included)
-
Maximum Compatibility
CPU Height : 198mm
GPU Length : 490mm
PSU Length : 200mm
-
Vertical GPU Mount
Yes
*54mm total clearance, standard 2-slot GPU (<38mm thickness) recommended for optimum cooling
-
Dust Filters
Bottom
-
RGB Lighting
Yes (Support RGB Fusion 2.0)
-
Weight
N.W. 19.2 Kg
-
Package Dimensions
H=773 W=406 D=820 mm
-
Accessories
1. Manual
2. Accessories kit
