Eaton UPS 9SX 3000i 2U Rack

Vendor: Eaton
SKU: 9SX3000IR
Availability: In Stock
Product Type: UPS
60,000.00 EGP
60,000.00 EGP
Limited-Time Offers, End in: 151D 8H 23M 0S

SHIPPING ALL ACROSS EGYPT!

Safe shipping

Estimated to be delivered on 1-5 Working Days .

Enjoy With Compumarts Warranty

Learn More.
9SX-3000i-2U-Rack-UPS-Eaton

Eaton UPS 9SX 3000i 2U Rack

60,000.00 EGP

Eaton UPS 9SX 3000i 2U Rack

60,000.00 EGP

Eaton UPS 9SX 3000i 2U Rack



Eaton OnLine 9SX UPS, 3000 VA, 2700 W, Input: C20, Outputs: (8) C13, (1) C19, Rack, 2U
Provides more real power (watts) to protect more equipment with a 0.9 power factor, Advanced Battery Management (ABM) technology to increase battery lifetime, Next-generation graphical LCD display, Meter energy consumption (at the UPS level), Hot-swappable batteries, Long backup time with up to 4 optional EBM, Load segment control enables prioritized shutdowns of non-essential equipment to maximize battery runtime for critical devices

  • Rating VA:3000

  • Rating Watt:2700

  • P.F:0.9

  • No. Of Outlets:(8) C13, (1) C19

  • LCD: Yes

  • Smart USB communication: Yes

  • Network Card: Yes

  • Free Management Software: ipp

  • Battery Charging Technology: ABM



PRODUCT NAME

Eaton 9SX UPS

CATALOG NUMBER

9SX3000IR

UPC

743172091147

PRODUCT LENGTH/DEPTH

608 mm

PRODUCT HEIGHT

86.5 mm

PRODUCT WIDTH

438 mm

PRODUCT WEIGHT

26.5 kg

COMPLIANCES

CE Marked

TUV

cULus Listed

CSA 22.2

FCC part 15 Class B

CISPR22 Class B

CERTIFICATIONS

IEC/EN 62040-1

UL 1778

IEC/EN 62040-2

CE

cULus Listed

EAC

BATTERY TYPE

Sealed, lead-acid

RUNTIME GRAPH

Check the graph above

BATTERY REPLACEMENT

Hot-swappable internal batteries and extended battery modules (EBMs)

BATTERY QUANTITY

6

BATTERY MANAGEMENT

ABM & Temperature compensated charging method (user selectable)

Automatic battery test

Deep discharge protection

Automatic recognition of external battery units

BATTERY RATING

12 V / 9 Ah

EXTENDED BATTERY CAPABILITY

Yes

RECEPTACLE

(8) C13, (1) C19

VOLTAGE

230V

WATTAGE

2700 W

OUTPUT POWER FACTOR

0.9

OUTPUT VOLTAGE RANGE

200/208/220/230/240 V +/- 2%

OUTPUT WAVEFORM

Sine wave

OUTPUT NOMINAL VOLTAGE

230V default (200/208/220/230/240V)

VOLTAGE DISTORTION OUTPUT (LINEAR LOAD) - MAX

3

FEED TYPE

1

TOPOLOGY

Online/Double-conversion

VA RATING

3000 VA

INPUT CONNECTION

C20

INPUT NOMINAL VOLTAGE

230V default (200/208/220/230/240/250V)

NOMINAL FREQUENCY

50/60 Hz

INPUT POWER FACTOR

>.99

INPUT CORD LENGTH

1.8m

INPUT VOLTAGE RANGE

200-276 Vac without derating (up to 140-276 Vac with derating)

INPUT FREQUENCY RANGE

40-70 Hz

INCLUDES NETWORK CARD

No

COMMUNICATION

USB port (HID compliant)

Serial port (RS232)

Mini-terminal block for remote power off

Mini-terminal block for output relay

Dry contacts (2 outputs, 1 input, optocoupler, DB9)

ETHERNET INTERFACE

No

USER INTERFACE

Multilingual graphical LCD display

POTENTIAL FREE SWITCH CONTACT

Yes

EXPANSION SLOTS

One slot for optional communication card

SOFTWARE COMPATIBILITY

Eaton Intelligent Power Manager, Eaton Intelligent Power Protector

TYPE OF INTERFACE

Other

ALTITUDE

3000 m

NOISE LEVEL

45 dB at 1 meter

TEMPERATURE RANGE

0° to 40°C (32° to 104°F)

RELATIVE HUMIDITY

0-96% non-condensing

CONSTRUCTION TYPE

482.6 mm (19 inch) device

PACKAGE CONTENTS

UPS

Input cable

(2) IEC-IEC output cables

USB cable

Serial cable

(2) brackets for 19’ mounting

(2) Rack-mounting kit

Safety instructions

Quickstart guide

PHASE (OUTPUT)

1

INTERNAL BYPASS

Yes

AUTO SHUTDOWN FUNCTION

Yes

COLOR

Black

EFFICIENCY

92

RACK MOUNTING KIT

Yes

PHASE (INPUT)

1

HOT SWAP POWER

No

CONSTRUCTION TYPE

482.6 mm (19 inch) device

PACKAGE CONTENTS

UPS

Input cable

(2) IEC-IEC output cables

USB cable

Serial cable

(2) brackets for 19’ mounting

(2) Rack-mounting kit

Safety instructions

Quickstart guide

PHASE (OUTPUT)

1

INTERNAL BYPASS

Yes

AUTO SHUTDOWN FUNCTION

Yes

COLOR

Black

EFFICIENCY

92

RACK MOUNTING KIT

Yes

PHASE (INPUT)

1

HOT SWAP POWER

No
