Intel Core i7-14700K TRAY

Intel Core i7-14700K - 14th Gen 20-Core (8P+12E) LGA 1700 125W Intel UHD Graphics

• Game Without Compromise. Play harder and work smarter with Intel Core 14th Gen processors

• 20 cores (8 P-cores + 12 E-cores) and 28 threads. Integrated Intel UHD Graphics 770 included

• Up to 5.6 GHz with Turbo Boost Max Technology 3.0 gives you smooth game play, high frame rates, and rapid responsiveness

• Compatible with Intel 600-series (with potential BIOS update) or 700-series chipset-based motherboards

• DDR4 and DDR5 platform support cuts your load times and gives you the space to run the most demanding games

CPU Specifications

Total Cores

20

Max of Performance-cores

8

Max of Efficient-cores

12

Total Threads

28

Max Turbo Frequency

5.6 GHz

Intel Turbo Boost Max Technology 3.0 Frequency

5.6 GHz

Performance-core Max Turbo Frequency

5.5 GHz

Efficient-core Max Turbo Frequency

4.3 GHz

Performance-core Base Frequency

3.4 GHz

Efficient-core Base Frequency

2.5 GHz

Cache

33 MB Intel Smart Cache

Total L2 Cache

28 MB

Processor Base Power

125 W

Maximum Turbo Power

253 W

Supplemental Information

Marketing Status

Launched

Launch Date

Q4'23

Embedded Options Available

No

Memory Specifications

Max Memory Size (dependent on memory type)

192 GB

Memory Types

Up to DDR5 5600 MT/s
Up to DDR4 3200 MT/s

Max of Memory Channels

2

Max Memory Bandwidth

89.6 GB/s

ECC Memory Supported

Yes

GPU Specifications

Processor Graphics

Intel UHD Graphics 770

Graphics Base Frequency

300 MHz

Graphics Max Dynamic Frequency

1.6 GHz

Graphics Output

eDP 1.4b, DP 1.4a, HDMI 2.1

Execution Units

32

Max Resolution (HDMI)^‡

4096 x 2160  60Hz

Max Resolution (DP)‡

7680 x 4320  60Hz

Max Resolution (eDP - Integrated Flat Panel)‡

5120 x 3200  120Hz

DirectX* Support

12

OpenGL* Support

4.5

OpenCL* Support

3.0

Multi-Format Codec Engines

2

Intel Quick Sync Video

Yes

Intel Clear Video HD Technology

Yes

Max of Displays Supported

4

Device ID

0xA780

Expansion Options

Direct Media Interface (DMI) Revision

4.0

Max of DMI Lanes

8

Scalability

1S Only

PCI Express Revision

5.0 and 4.0

PCI Express Configurations

Up to 1x16+4, 2x8+4

Max of PCI Express Lanes

20

Package Specifications

Sockets Supported

FCLGA1700

Max CPU Configuration

1

Thermal Solution Specification

PCG 2020A

T_JUNCTION

100°C

Package Size

45.0 mm x 37.5 mm

Advanced Technologies

Intel Gaussian & Neural Accelerator

3.0

Intel Thread Director

Yes

Intel Deep Learning Boost (Intel DL Boost) on CPU

Yes

Intel Speed Shift Technology

Yes

Intel Turbo Boost Max Technology 3.0

Yes

Intel Turbo Boost Technology

2.0

Intel Hyper-Threading Technology

Yes

Intel 64

Yes

Instruction Set

64-bit

Instruction Set Extensions

Intel SSE4.1, Intel SSE4.2, Intel AVX2

Idle States

Yes

Enhanced Intel SpeedStep Technology

Yes

Thermal Monitoring Technologies

Yes

Intel Volume Management Device (VMD)

Yes
