Lenovo Legion 5 16IRX9 Gaming - Intel i7-13650HX 14 Core, NVIDIA RTX 4060 8GB GDDR6,16GB DDR5-4800 RAM, 1TB SSD , 16" WQXGA IPS 350nits sRGB 165Hz G-SYNC, RGB -Win 11

Lenovo Legion 5 16IRX9 Gaming - Intel i7-13650HX 14 Core, NVIDIA RTX 4060 8GB GDDR6,16GB DDR5-4800 RAM, 1TB SSD , 16" WQXGA IPS 350nits sRGB 165Hz G-SYNC, RGB -Win 11

Processor
Intel Core i7-13650HX 14C 6P plus 8E 20T P-core 2.6 4.9GHz E-core 1.9 3.6GHz 24MB

AI PC Category
AI-Powered Gaming PC

Graphics
NVIDIA GeForce RTX 4060 8GB GDDR6 Boost Clock 2370MHz TGP 140W 233 AI TOPS

Chipset
Intel HM770 Chipset

Memory
2x 8GB SO-DIMM DDR5-4800

Memory Slots
Two DDR5 SO-DIMM slots dual-channel capable

Max Memory
Up to 64GB DDR5-4800

Storage
1TB SSD M.2 2242 PCIe 4.0x4 NVMe

Storage Support
Up to two drives 2x M.2 SSD
M.2 2242 SSD up to 1TB
M.2 2280 SSD up to 1TB

Storage Slot
Two M.2 2280 PCIe 4.0 x4 slots

Card Reader
microSD Card Reader

Optical
None

Audio Chip
High Definition HD Audio Realtek ALC3287 codec

Speakers
Stereo speakers 2W x2 optimized with Nahimic Audio

Camera
FHD 1080p with E-shutter

Microphone
2x Array

Battery
Integrated 80Wh

Power Adapter
230W Slim Tip 3-pin

Special Features
AI Chip LA1

Display
16 WQXGA 2560x1600 IPS 350nits Anti-glare 100 percent sRGB 165Hz Dolby Vision G-SYNC Low Blue Light

Touchscreen
None

Color Calibration
Factory Color Calibration

Keyboard
4-Zone RGB Backlit English US

Touchpad
Buttonless Mylar surface multi-touch touchpad 75 x 120 mm 2.95 x 4.72 inches

Case Color
Luna Grey

Surface Treatment
Aluminium Stamping Anodized with Sandblasting

Case Material
Aluminium Top PC-ABS Bottom

Pen
Pen Not Supported

Dimensions WxDxH
359.7 x 262.3 x 19.7-25.2 mm 14.16 x 10.33 x 0.78-0.99 inches

Weight
Around 2.36 kg 5.2 lbs

Operating System
Windows 11 Home English

Bundled Software
Office Trial

Ethernet
100/1000M RJ-45

WLAN plus Bluetooth
Wi-Fi 6E 802.11ax 2x2 plus BT5.2

WWAN
Non-WWAN

Standard Ports
2x USB-A USB 5Gbps USB 3.2 Gen 1
1x USB-A USB 5Gbps USB 3.2 Gen 1 Always On
1x USB-C USB 10Gbps USB 3.2 Gen 2 with Lenovo PD 140W and DisplayPort 1.4
1x USB-C USB 10Gbps USB 3.2 Gen 2 with DisplayPort 1.4
1x HDMI 2.1 up to 8K 60Hz
1x Headphone microphone combo jack 3.5mm
1x Ethernet RJ-45
1x Card reader
1x Power connector

Security Chip
Firmware TPM 2.0 Enabled

Fingerprint Reader
None

Other Security
E-shutter

Base Warranty
1-year Courier or Carry-in

Included Upgrade
None

Bundled Accessories
None

Green Certifications
ErP Lot 6/26
RoHS compliant

Other Certifications
TÜV Rheinland Low Blue Light Hardware Solution
