Lenovo V15-ADA 82C7007YED Laptop - AMD 3020e 4 GB RAM 1TB HDD Integrated AMD Radeon Graphics 15.6" HD (1366x768) TN 220nits Anti-glare Dos Iron Grey

Lenovo V15-ADA 82C7007YED Laptop - AMD 3020e, 4 GB RAM, 1TB HDD, Integrated AMD Radeon Graphics, 15.6" HD (1366x768) TN 220nits Anti-glare, Dos – Iron Grey

1. Power connector	5. Power indicator
2. HDMI 1.4b	6. NOVO button hole
3. USB 2.0	7. Headphone / microphone combo jack (3.5mm)
4. 2x USB 3.1 Gen 1	8. Card reader

Performance

Processor Family

AMD 3000, AMD Athlon, or AMD Ryzen 3 / 5 Processor

Processor

Processor Name	Cores	Threads	Base Frequency	Max Frequency	Cache	Memory Support	Processor Graphics
AMD 3020e	2	2	1.2GHz	2.6GHz	1MB L2 / 4MB L3	DDR4-2400	AMD Radeon™ Graphic

Operating System

• FreeDOS

Graphics

Graphics	Type	Memory	Key Features
AMD Radeon Graphics	Integrated	Shared	DirectX 12
AMD Radeon Vega 8 Graphics	Integrated	Shared	DirectX 12

Monitor Support

Monitor Support

Supports up to 2 independent displays (native display and 1 external monitor via HDMI) • HDMI supports up to 3840x2160 30Hz

Chipset

Chipset

AMD SoC (System on Chip) platform

Memory

Max Memory^[1]

• Up to 8GB (8GB SO-DIMM) DDR4-2400

• Up to 12GB (4GB soldered + 8GB SO-DIMM) DDR4-2400

Memory Slots^[2]

• One DDR4 SO-DIMM slot

• One memory soldered to systemboard, one DDR4 SO-DIMM slot

Memory Type

DDR4-2400

Storage Support

Up to two drives, 1x 2.5" HDD + 1x M.2 SSD • 2.5" HDD up to 1TB • M.2 2242 SSD up to 512GB • M.2 2280 SSD up to 512GB

Storage Type

Disk Type	Interface	RPM	Security
2.5" SATA HDD	SATA 6Gb/s	5.4K	-
M.2 2242 SSD	PCIe NVMe, PCIe 3.0 x2	-	-
M.2 2280 SSD	PCIe NVMe, PCIe 3.0 x4	-	-

Removable Storage

Optical

None

Card Reader

4-in-1 card reader (SD, SDHC, SDXC, MMC)

Multi-Media

Audio Chip

High Definition (HD) Audio

Speakers

Stereo speakers, 1.5W x2, Dolby Audio

Microphone

Single microphone

Camera

0.3-megapixel, fixed focus

Battery

• Integrated Li-Polymer 30Wh battery

• Integrated Li-Polymer 35Wh battery

Max Battery Life^[1]

• MobileMark 2014: 5 hr (30Wh)

• MobileMark 2014: 6 hr (35Wh)

Power Adapter

65W round tip (2-pin, wall-mount) AC adapter, 100-240V, 50-60Hz

Design

Display

Display

Size	Resolution	Touch	Type	Brightness	Surface	Aspect Ratio	Contrast Ratio	Color Gamut	Viewing Angle	Key Features
15.6"	HD (1366x768)	None	TN	220 nits	Anti-glare	16:9	-	-

Touchscreen

Non-touch

Input Device

Keyboard

6-row, spill-resistant, multimedia Fn keys, numeric keypad

Keyboard Backlight

Non-backlight

Touchpad

Buttonless Mylar surface multi-touch touchpad

Mechanical^[1]

Dimensions (WxDxH)

362.2 x 251.5 x 19.9 mm (14.26 x 9.9 x 0.78 inches)

Weight

Starting at 1.85 kg (4.08 lbs)

Case Color

Iron grey

Surface Treatment

• IMR (in-mold decoration by roller)

• Texture

Case Material

PC + ABS (top), PC + ABS (bottom)

Connectivity

NetworkOnboard Ethernet

No Ethernet

WLAN + Bluetooth^[1]

802.11ac 2x2 Wi-Fi + Bluetooth 5.0, M.2 card

Ports^[1]

Standard Ports

• 1x USB 2.0

• 2x USB 3.1 Gen 1

• 1x HDMI 1.4b

• 1x Card reader

• 1x Headphone / microphone combo jack (3.5mm)

• 1x Power connector

Security & Privacy

Security

Security Chip

Firmware TPM 2.0 integrated in SoC

Fingerprint Reader

No fingerprint reader

BIOS Security

• Power-on password

• Supervisor password

• Hard disk password

Service

Warranty

Base Warranty

• 1-year depot service

• 2-year (1-yr battery) depot service

Environmental

Operating Environment

Temperature^[1]

• At altitudes up to 2438 m (8,000 ft) - Operating: 5°C to 35°C (41°F to 95°F) - Storage: 5°C to 43°C (41°F to 109°F)

• At altitudes above 2438 m (8,000 ft) - Maximum temperature when operating under the unpressurized condition: 31.3°C (88°F)

Humidity

• Operating: 8% to 95% at wet-bulb temperature 23°C (73°F)

• Storage: 5% to 95% at wet-bulb temperature 27°C (81°F)

Altitude

Maximum altitude (without pressurization): 3048 m (10,000 ft)

• Certifications

Green Certifications

Green Certifications

• ErP Lot 3

• RoHS compliant

PERFORMANCE
Processor	AMD 3020e (2C / 2T, 1.2 / 2.6GHz, 1MB L2 / 4MB L3)
Graphics	Integrated AMD Radeon Graphics
Chipset	MD SoC Platform
Memory	4GB SO-DIMM DDR4-2400
Memory Slots	One DDR4 SO-DIMM slot
Max Memory	Up to 8GB (8GB SO-DIMM) DDR4-2400
Storage	1TB HDD 5400rpm 2.5"
Storage Support	Up to two drives, 1x 2.5" HDD + 1x M.2 SSD • 2.5" HDD up to 1TB • M.2 2242 SSD up to 512GB • M.2 2280 SSD up to 512GB
Card Reader	4-in-1 Card Reader
Optical	None
Audio Chip	High Definition (HD) Audio
Speakers	Stereo speakers, 1.5W x2, Dolby Audio
Camera	0.3MP
Microphone	Mono
Battery	Integrated 35Wh
Max Battery Life	MobileMark 2014: 6 hr (35Wh)
Power Adapter	65W Round Tip (2-pin, Wall-mount)
DESIGN
Display	15.6" HD (1366x768) TN 220nits Anti-glare
Touchscreen	None
Keyboard	Non-backlit, Arabic
Case Color	Iron Grey
Surface Treatment	Texture
Case Material	PC + ABS (Top), PC + ABS (Bottom)
Dimensions (WxDxH)	362.2 x 251.5 x 19.9 mm (14.26 x 9.9 x 0.78 inches)
Weight	Starting at 1.85 kg (4.08 lbs)
SOFTWARE
Operating System	FreeDOS
Bundled Software	None
CONNECTIVITY
Ethernet	None
WLAN + Bluetooth	11ac, 2x2 + BT5.0
Standard Ports	1x USB 2.0 2x USB 3.1 Gen 1 1x HDMI 1.4b 1x Card reader 1x Headphone / microphone combo jack (3.5mm) 1x Power connector
SECURITY & PRIVACY
Security Chip	Firmware TPM 2.0
Fingerprint Reader	None
SERVICE
Base Warranty	1-year, Depot
Included Upgrade	None
CERTIFICATIONS
Green Certifications	ErP Lot 3 RoHS compliant
