Display Size (in.):
|
24
|
Viewable Area (in.):
|
23.8
|
Panel Type:
|
VA Technology
|
Resolution:
|
1920 x 1080
|
Resolution Type:
|
FHD (Full HD)
|
Static Contrast Ratio:
|
5,000:1 (typ)
|
Dynamic Contrast Ratio:
|
50M:1
|
Light Source:
|
LED
|
Brightness:
|
250 cd/m² (typ)
|
__Brightness (PCS):
|
250 cd/m² (typ)
|
Colors:
|
16.7M
|
Color Space Support:
|
8 bit (6 bit + FRC)
|
Aspect Ratio:
|
16:9
|
Response Time (Typical GTG):
|
4ms
|
Viewing Angles:
|
178º horizontal, 178º vertical
|
Backlight Life (Hours):
|
30000 Hrs (Min)
|
Curvature:
|
Flat
|
Refresh Rate (Hz):
|
75
|
Blue Light Filter:
|
Yes
|
Flicker-Free:
|
Yes
|
Color Gamut:
|
NTSC: 72% size (Typ) sRGB: 103% size (Typ)
|
Pixel Size:
|
0.275 mm (H) x 0.275 mm (V)
|
Surface Treatment:
|
Anti-Glare (Semi-Glossy), Hard Coating (2H)
|
-
COMPATIBILITY
PC Resolution (max):
|
1920x1080
|
Mac Resolution (max):
|
1920x1080
|
PC Operating System:
|
Windows 10/11 certified; macOS tested
|
Mac Resolution (min):
|
1920x1080
|
-
CONNECTOR
VGA:
|
1
|
3.5mm Audio Out:
|
1
|
HDMI 1.4:
|
1
|
Power in:
|
DC Socket (Center Positive)
|
-
POWER
Eco Mode (Conserve):
|
18W
|
Eco Mode (optimized):
|
22W
|
Consumption (typical):
|
25W
|
Consumption (max):
|
27W
|
Voltage:
|
AC 100-240V
|
Stand-by:
|
0.3W
|
Power Supply:
|
External Power Adaptor
|
-
ADDITIONAL HARDWARE
-
CONTROLS
Physical Controls:
|
Key 1 (favorite), Key 2, Key 3, Key 4, Key 5 (power)
|
On Screen Display:
|
Input Select, Audio Adjust, ViewMode, Color Adjust, Manual Image Adjust, Setup Menu
|
-
OPERATING CONDITIONS
Temperature:
|
32°F to 104°F (0°C to 40°C)
|
Humidity (non-condensing):
|
20% to 90%
|
-
WALL MOUNT
VESA Compatible:
|
100 x 100 mm
|
-
INPUT SIGNAL
Frequency Horizontal:
|
24 ~ 86KHz
|
Frequency Vertical:
|
50 ~ 75Hz
|
-
VIDEO INPUT
Digital Sync:
|
TMDS - HDMI (v1.4)
|
Analog Sync:
|
Separate - RGB Analog
|
-
ERGONOMICS
Tilt (Forward/Back):
|
-3º / 20º
|
-
WEIGHT (IMPERIAL)
Net (lbs):
|
7.5
|
Net Without Stand (lbs):
|
6.6
|
Gross (lbs):
|
10.6
|
-
WEIGHT (METRIC)
Net (kg):
|
3.4
|
Net Without Stand (kg):
|
3
|
Gross (kg):
|
4.8
|
-
DIMENSIONS (IMPERIAL) (WXHXD)
Packaging (in.):
|
24.5 x 16.5 x 5.7
|
Physical (in.):
|
21.2 x 16.6 x 7.4
|
Physical Without Stand (in.):
|
21.2 x 12.7 x 2
|
-
DIMENSIONS (METRIC) (WXHXD)
Packaging (mm):
|
622 x 420 x 144
|
Physical (mm):
|
540 x 423 x 189
|
Physical Without Stand (mm):
|
540 x 323 x 51
|
-
SuperClear VA panel
-
Eye-care technology for comfortable viewing
-
Eco-mode for low energy consumption
-
ViewMode color rendering options
-
HDMI and VGA inputs for connectivity
The ViewSonic VA2406-h-2 is a 24” Full HD monitor with HDMI and VGA input for business or home usage. Delivering a stunning image quality with low power consumption, this monitor provides six ViewMode presets that deliver optimized screen performance based on your needs. The eye care technology that comes standard with all VA monitors helps to eliminate eyestrain from extended viewing periods. A VESA-compatible mount makes this monitor is easy to setup on the wall or with a wide range of industry-standard mounts.
-
Menu Control Panel
-
VESA Compatible(Wall Mount 100 x 100mm)
-
HDMI
-
VGA
-
Earphone
-
DC in
