SPIDER Man Bundle CORE i5-14400F - RAM TEAM ELITE 16GB DDR5 - SSD LEXAR NM620 500GB - ZOTAC RTX 4060 TI SPIDER

SPIDER Man Bundle CORE i5-14400F - RAM TEAM ELITE 16GB DDR5 - SSD LEXAR NM620 500GB - ZOTAC RTX 4060 TI SPIDER



Intel Core i5  14400F 20M Cache, up to 4.70 GHz processor



Code Name

Products formerly Raptor Lake

Vertical Segment

Desktop

Processor Number

i5-14400F

Lithography

Intel 7

Use Conditions

PC/Client/Tablet

CPU Specifications

Total Cores

10

# of Performance-cores

6

# of Efficient-cores

4

Total Threads

16

Max Turbo Frequency

4.7 GHz

Performance-core Max Turbo Frequency

4.7 GHz

Efficient-core Max Turbo Frequency

3.5 GHz

Performance-core Base Frequency

2.5 GHz

Efficient-core Base Frequency

1.8 GHz

Cache

20 MB Intel Smart Cache

Total L2 Cache

9.5 MB

Processor Base Power

65 W

Maximum Turbo Power

148 W

Supplemental Information

Marketing Status

Launched

Launch Date

Q1'24

Embedded Options Available

No

Memory Specifications

Max Memory Size (dependent on memory type)

192 GB

Memory Types

Up to DDR5 4800 MT/s
Up to DDR4 3200 MT/s

Max # of Memory Channels

2

Max Memory Bandwidth

76.8 GB/s

Expansion Options

Direct Media Interface (DMI) Revision

4.0

Max # of DMI Lanes

8

Scalability

1S Only

PCI Express Revision

5.0 and 4.0

PCI Express Configurations

Up to 1x16+4, 2x8+4

Max # of PCI Express Lanes

20

Package Specifications

Sockets Supported

FCLGA1700

Max CPU Configuration

1

Thermal Solution Specification

PCG 2020C

T_JUNCTION

100°C

Package Size

45.0 mm x 37.5 mm

Advanced Technologies

Intel Gaussian & Neural Accelerator

3.0

Intel Thread Director

Yes

Intel Deep Learning Boost (Intel DL Boost) on CPU

Yes

Intel Speed Shift Technology

Yes

Intel Turbo Boost Technology

2.0

Intel Hyper-Threading Technology

Yes

Intel 64

Yes

Instruction Set

64-bit

Instruction Set Extensions

Intel SSE4.1, Intel SSE4.2, Intel AVX2

Idle States

Yes

Enhanced Intel SpeedStep Technology

Yes

Thermal Monitoring Technologies

Yes

Intel Volume Management Device (VMD)

Yes

Security & Reliability

Intel Standard Manageability (ISM)

Yes

Intel Control-Flow Enforcement Technology

Yes

Intel AES New Instructions

Yes

Secure Key

Yes

Intel OS Guard

Yes

Execute Disable Bit

Yes

Intel Boot Guard

Yes

Mode-based Execute Control (MBEC)

Yes

Intel Virtualization Technology (VT-x)

Yes

Intel Virtualization Technology for Directed I/O (VT-d)

Yes

Intel VT-x with Extended Page Tables (EPT)

Yes



ZOTAC GAMING GeForce RTX 4060 Ti 8GB Twin Edge OC SPIDER-MAN Across the Spider-Verse Bundle





The ZOTAC GAMING GeForce RTX 4060 Ti 8GB Twin Edge OC is a compact and powerful graphics card, featuring the NVIDIA Ada Lovelace architecture and an aerodynamic-inspired design. With a reduced 2.2 slot size, it's an excellent choice for those who want to build a SFF gaming PC capable of smooth framerate and performance in the latest title releases.

This Spider-Man: Across the Spider-Verse inspired bundle includes a number of themed goodies, such as a themed magnetic backplate and custom fan emblems to make the Twin Edge OC extra stylish, as well as a tote bag and a set of decorative decals that fans are sure to love.

Feature Highlights:
- Powered by NVIDIA DLSS 3, ultra-efficient Ada Lovelace arch, and full ray tracing
- IceStorm 2.0 Advanced Cooling
- FREEZE Fan Stop, Active Fan Control
- Compact 2.2 Slot Footprint
- SPECTRA RGB Lighting
- Metal Backplate
- All-new FireStorm Utility



• GPU : GeForce RTX 4060 Ti

• CUDA cores : 4352

• Video Memory : 8GB GDDR6

• Memory Bus : 128-bit

• Engine Clock : Boost: 2550MHz

• Memory Clock : 18 Gbps

• PCI Express : 4.0 x8

• Display Outputs

  3 x DisplayPort 1.4a (up to 7680x4320@60Hz)
  1 x HDMI Connector*
  *Supports 4K 120Hz HDR, 8K 60Hz HDR, and Variable Refresh Rate as specified in the HDMI 2.1a Specification

• HDCP Support : 2.3

• Multi Display Capability : Quad Display

• Recommended Power Supply : 500W

• Power Consumption : 160W

• Power Input : 1 x 8-pin PCIe

• DirectX : 12 Ultimate

• OpenGL :4.6

• Cooling : IceStorm 2.0

• Slot Size : 2.2 slot

• SLI : N/A

• Supported OS : Windows 11 / 10 (64-bit, v1809 November 2018 or later)

• Card Length : 225.5mm x 123.2mm x 40.1mm / 8.9" x 4.9" x 1.6"

• Accessories

  User Manual
  Themed Magnetic Backplate (approx. 3mm thick)
  Themed Fan Emblem Badges
  Decals
  Tote Bag



ASUS Prime B760M-K Intel B760 LGA 1700 mATX motherboard with PCIe 4.0, two PCIe 4.0 M.2 slots, DDR5

Audio

Back Panel I/O Ports

4 x USB 3.2 Gen 1 (5G) ports (4 x Type-A)

2 x USB 2.0 ports (2 x Type-A)

1 x VGA port

1 x HDMI port

1 x Realtek 2.5Gb Ethernet port

3 x Audio jacks

1 x PS/2 Keyboard/Mouse combo port

Internal I/O Connectors

BIOS

128 Mb Flash ROM, UEFI AMI BIOS

Manageability

WOL by PME, PXE

Accessories

Cables
2 x SATA 6Gb/s cables

Miscellaneous

1 x I/O Shield

2 x M.2 anchors

Documentation

1 x User guide



Operating System

Windows 11, Windows 10 64-bit



Form Factor



TEAM Elite plus 1x16GB , DDR5 (Black)



• Compatible with DDR5 platforms of Intel and AMD systems.

• Effective power system configuration with low voltage for power reduction.

• Optimized structure with exceptional access efficiency.

• On-Die ECC mechanism for enhanced data transmission stability.

• Lifetime warranty and Free technical support.

Symmetrical heat sink

Through special processing, the heat sink in plain design is equipped with properties including scratch resistance, acid resistance, anti-corrosion, and non-conduction, offering comprehensive protection for the DDR5 memory module.

Frequency further enhanced for upgraded performance

In compliance with JEDEC, DDR5 increased performance by over 50% from that of the DDR4 with a 3200MHz limit. The enhanced speed enables upgraded high-performance operation quality.

Effective power system configuration with low voltage for power reduction

The standard operating voltage of DDR5 is 1.1V, compared with the 1.2V required for DDR4, it reduces the power consumption of bandwidth units and computer loading.

Transcend capacity limit with diverse upgrade options

ELITE PLUS DDR5 comes with a complete range of sing-channel and dual-channel specifications from 8GB to 32GB.

Optimized structure with exceptional access efficiency

The structure of the DDR5 module, compared with that of DDR4, has increased the number of banks from 16 to 32. It can process doubled data volume in the same amount of time, which is key to improving operational efficiency.

On-Die ECC mechanism for enhanced data transmission stability

DDR5 memory module supports On-die ECC error correction. It can repair DRAM units through its built-in functions to reduce the risk of data errors, offering enhanced stability to systems that adopt ELITE PLUS DDR5.

Module Type	DDR5 288 Pin Non-ECC Unbuffered DIMM
Frequency	4800	5200	5600	6000
Latency	CL40-40-40-77	CL42-42-42-84	CL46-46-46-90	CL48-48-48-96
Capacity	8GB 16GB 32GB 8GBx2 16GBx2 32GBx2	8GB 16GB 32GB 8GBx2 16GBx2 32GBx2	16GB 16GBx2	16GB 16GBx2
Data Transfer Bandwidth	38,400 MB/s (PC5 38400)	41,600 MB/s (PC5 41600)	44,800 MB/s (PC5 44800)	48,000 MB/s (PC5 48000)
Voltage	1.1V	1.1V	1.1V	1.1V
Compatibility	Intel: 600 Series, 700 Series AMD: 600 Series		Intel: 600 Series, 700 Series
Dimensions	31.25(H) x 133.4(L) x 6.6(W)mm
Heat Sink	Aluminum heat-sink
Model Brand Team Series Elite Plus Model TPBD516G5600HC4601

Details

Capacity	16GB
Type	288-Pin PC RAM
Speed	DDR5 5600 (PC5 44800)
CAS Latency	46
Timing	46-46-46-90
Voltage	1.10V
Color	Black



Lexar NM620 M.2 2280 Internal SSD



Weight	1 kg
Capacity	1TB, 256GB, 2TB, 512GB
brands	Lexar





With speeds of up to 3300MB/s read, enjoy 6x the speed of SATA SSDs3. The NM620 puts you in the computing fast lane and offers impressive performance for demanding creative workstations and gaming experiences.



 Features LDPC for added reliability

Low-Density Parity Check (LDPC) technology makes data transfers more reliable than ever by fixing data errors before they have a chance to slow you down.



Unlike traditional hard disk drives, the NM620 SSD has no moving parts, so it’s built to last. On top of that, it’s also shock and vibration resistant2, making it one robust and reliable SSD.

Efficient

Reduced power consumption and cooler operation makes the battery life last longer than a traditional hard drive



COUGAR Case DUOFACE 3 FAN RGB POWER VTE X2 650W

Case Form Factor Mid Tower

Motherboard Type Mini ITX / Micro ATX / ATX / CEB / *E-ATX

Dimensions (WxHxD) 230 x 491 x 386 (mm)

9.1 x 19.3 x 15.2 (in)

I/O Panel USB 3.0 x 2, USB 2.0 x 1, 4 Pole Headset Audio Jack x1, RGB Button

3.5" Drive Bay 2

2.5" Drive Bay 2 (2 SSD trays included)

Expansion Slots 7+3

Vertical GPU Support Yes

Cooling Fan Support Front 120mm x 2 / 140mm x 2

Top 120mm x 2 / 140mm x 2

Rear 120mm x 1 / 140mm x 1

Pre-installed Fans Front 140mm ARGB fan x 2

Rear 120mm ARGB fan x 1

Speed 1000 RPM

Connector 5V 3 Pin (ARGB) / 3 Pin (Fan)

Maximun Number of Fans 5 Max.

Water Cooling Support Front *280mm / 240mm / 140mm / 120mm

Top *280mm / 240mm / 140mm / 120mm

Rear 120mm / 140mm

Transparent Left Panel 4mm Tempered Glass

Onboard Lighting System Yes

RGB Sync with M/B Yes

COUGAR Logo RGB Light Yes

Max. Graphics Card Length 330 (mm) / 13 (in)

Max. CPU Cooler Height 190 (mm) / 7.5 (in)

Max. PSU Length 160 (mm) / 6.3 (in)
